15
Before you connect your television to another device, please refer to the proper diagrams for
your specific TV and remote. These will help assist you in understanding how to connect your
television to another device, as well as use the remote to set up your television. Some of the
connection terminals are color coded for easy connection with the proper cables.
To find the best possible connection that your device can use, see pages 16 - 17.
For more detailed information about connecting external devices, see pages 44 - 49.
Game Console
Video Camera
STB (Digital Cable,
satellite) Tuner Box
DVD Player
HDMI
(INPUT 1, 2, or 3)
HDMI ANALOG AUDIO
Composite / Component
(INPUT 4 or 5)
S-Video
3
1
6
4
2
5
DIGITAL AUDIO
OPTICAL OUT
AUDIO OUT
Antenna / Cable
7
8
Audio System
Basics
PC
D-SUB
9
PC (with HDMI)
LCT2520-001A-A.indd 15LCT2520-001A-A.indd 15 1/16/09 9:46:41 AM1/16/09 9:46:41 AM
