Item
Measuring
instrument
Test point Ad justment part Description
Ad ju st ment
of DELAY
POI NT
(AGC)
Signal
generator
Remote
control unit
DE LAY POINT
(AGC TAKE-OVER)
1. Input a blac k an d wh it e sign al ( colo ur of f).
2. En ter th e SERVICE MENU.
3. Select 1. IF f rom t he SERVI CE M ENU.
4. Select 2 . DELAY P OINT by pressin g th e 2 key on the remote
control unit.
5. Set the settin
g
valu es of th e set tin
g
item s as s ho wn bello w t able .
6. Then adjust the MENU - or + key until video noise disappears.
7. Tur n to oth er ch an nels and make su re that the re ar e n o
irregularities.
Setting Item Variabl e range Initial setting value
MATSUSHITA
(
QAU0287-001
)
NT SC 3.5 8
45
DE LAY POINT
(AGC TAKE OVER)
OTHER
0～127
35
DELAY POINT UHF
AGC TAKE-OVER
**
- / + : OPERATE DISP : EXIT
