JVC AV-21E3 User Manual

No. 52028
A
V-21E3
36
!
Symbol No. Part No. Part Name Description
CAPACITOR
C1741 QETN1HM-106Z E CAP. 10
µ
F 50V M
C1743 QETN1HM-106Z E CAP. 10µF 50V M
C1744 NCB31HK-103X C CAP. 0.01µF 50V K
C1805 QETN1CM-227Z E CAP. 220µF 16V M
C1806 QETN1CM-477Z E CAP. 470µF 16V M
C1811 QETN1HM-106Z E CAP. 10µF 50V M
C1841 NCB31HK-152X C CAP. 1500pF 50V K
! C1901 QFZ9078-224 MPF CAP. 0.22µFAC275V M
! C1904 QCZ9015-102 C CAP. 1000pFAC250V Z
!
C1905 QCZ9015-102 C CAP. 1000pFAC250V Z
!
C1907 QCZ9015-102 C CAP. 1000pFAC250V Z
! C1909 QEZ0552-127 E CAP. or QEZ0199-127 120µF 400V M
! C1910 QFZ9078-473 MPF CAP. 0.047µFAC275V M
C1922 QFLC1HJ-104Z M CAP. 0.1µF 50V J
C1924 QETN1HM-475Z E CAP. 4.7
µ
F 50V M
C1925 QETN1VM-476Z E CAP. 47
µ
F 35V M
C1926 QFLC1HJ-332Z M CAP. 3300pF 50V J
!
C1929 QFKA2JK-103 MM CAP. 0.01
µ
F 630V K
! C1931 QCZ0364-681 C CAP. 680pF 2kV K
C1932 NDC31HJ-221X C CAP. 220pF 50V J
C1941 QCZ0364-561 C CAP. 560pF 2kV K
C1942 QEZ0203-107 E CAP. 100µF 160V M
C1944 QCB32HK-222Z C CAP. 2200pF 500V K
C1945 QEHR1EM-108Z E CAP. 1000µF 25V M
C1946 QETN1EM-108Z E CAP. 1000µF 25V M
C1947 QCB32HK-222Z C CAP. 2200pF 500V K
C1948 QETN1EM-108Z E CAP. 1000µF 25V M
C1949 NDC31HJ-471X C CAP. 470pF 50V J
C1976 QETN1EM-227Z E CAP. 220µF 25V M
C1977 QETN1CM-227Z E CAP. 220µF 16V M
C1978 QETN1EM-227Z E CAP. 220
µ
F 25V M
C1979 QETN1AM-227Z E CAP. 220µF 10V M
!
C1991 QCZ9079-102 C CAP. 1000pFAC250V M
! C1992 QCZ9079-102 C CAP. 1000pFAC250V M
! C1993 QCZ9079-222 C CAP. 2200pFAC250V M
TRANSFORMER
T1501 QQR1244-001 DRIVE TRANSF
! T1522 QQH0134-001 FB TRANSF
!
T1921 QQS0161-001 SW TRANSF
COIL
L1001 QQL244K-8R2Z COIL 8.2µH K
L1101 QQL244J-2R2Z COIL 2.2
µ
H J
L1103 QQL244K-8R2Z COIL 8.2µH K
L1551 QQLZ034-360 INDUCTOR
L1701 QQL244J-5R6Z COIL 5.6
µ
H J
L1941 QQL26AK-820Z COIL 82µH K
L1942 QQL244J-4R7Z INDUCTOR
L1943 QQL244J-4R7Z INDUCTOR
DIODE
D1001 MTZJ33A-T2 Z DIODE
D1301 MTZJ9.1B-T2 Z DIODE
D1302 MTZJ9.1B-T2 Z DIODE
D1305 AK04-T2 SB DIODE
D1306 QRE121J-121Y C R 120Ω 1/2W J
D1341 MA111-X SI DIODE
D1421 MTZJ75-T2 Z DIODE
D1423 1SR124-400A-T2 SI DIODE
D1425 MA111-X SI DIODE
D1427 MTZJ27B-T2 Z DIODE
D1501 MTZJ6.8C-T2 Z DIODE
D1551 RGP10J-5025-T3 SI DIODE
D1552 RGP10J-5025-T3 SI DIODE
D1553 MTZJ9.1B-T2 Z DIODE
D1554 MA111-X SI DIODE
D1557 1SR124-400A-T2 SI DIODE
D1571 MTZJ7.5S-T2 Z DIODE
D1581 MTZJ20B-T2 Z DIODE
D1582 RGP10J-5025-T3 SI DIODE
D1651 MA111-X SI DIODE
D1652 MTZJ12C-T2 Z DIODE
D1653 MA111-X SI DIODE
!
Symbol No. Part No. Part Name Description
DIODE
D1654 MTZJ12C-T2 Z DIODE
D1655 MA111-X SI DIODE
D1656 MA111-X SI DIODE
D1657 MA111-X SI DIODE
D1701 MA111-X SI DIODE
D1704 SLR-342VR-T16 LED
D1705 SLR-342DU-T16 LED
D1707 MA111-X SI DIODE
D1731 MA111-X SI DIODE
! D1901 G2SBA60 BRIDGE DIODE
D1921 RGP10J-5025-T3 SI DIODE
D1925 RGP10J-5025-T3 SI DIODE
D1927 MTZJ36A-T2 Z DIODE
D1928 MTZJ3.3A-T2 Z DIODE
D1929 QRE141J-154Y C RESISTOR
D1930 RGP10M-5010-T3 SI DIO DE
D1931 MA111-X SI DIODE
D1933 MTZJ16C-T2 Z DIODE
D1941 RU3AM-LFC4 SI DIODE
D1942 RU3YX-LFC4 SI DIODE
D1943 RGP10J-5025-T3 SI DIODE
D1982 MA111-X SI DIODE
D1983 MA111-X SI DIODE
TRANSISTOR
Q1102 2SC5083/L-P/-T TRANSISTOR
Q1301 2SB709A/QR/-X TRANSISTOR
Q1302 2SD601A/QR/-X TRANSISTOR
Q1351 STC344-T TRANSISTOR
Q1352 STC344-T TRANSISTOR
Q1353 STC344-T TRANSISTOR
Q1401 DTC124ESA-T DIGI TRANSISTOR
Q1402 2SD601A/QR/-X TRANSISTOR
Q1403 2SD601A/QR/-X TRANSISTOR
Q1521 2SC2655/Y/-T TRANSISTOR
! Q1522 2SD2627-YB11 POW TRANSISTOR H.OUT
Q1571 2SA1208/ST/Z1-T TRANSISTOR
Q1572 2SD601A/QR/-X TRANSISTOR
Q1651 2SD601A/QR/-X TRANSISTOR
Q1652 2SD601A/QR/-X TRANSISTOR
Q1653 2SB709A/QR/-X TRANSISTOR
Q1702 2SD601A/QR/-X TRANSISTOR
Q1703 2SD601A/QR/-X TRANSISTOR
Q1708 UN2212-X DIGI TRANSISTOR
Q1709 2SB709A/QR/-X TRANSISTOR
Q1803 2SC1815/YG/-T TRANSISTOR
Q1804 2SD601A/QR/-X TRANSISTOR
Q1974 2SA966/OY/-T TRANSISTOR
Q1975 UN2212-X DIGI TRANSISTOR
IC
IC1301 NN5198K I C
IC1421 AN5522 I C
IC1651 AN5265 I C
! IC1701 MN1873287JJ1 I C(MCU)
IC1702 AT24C08-21DMG3 I C (SERVICE)
IC1703 L78LR05E-MA I C
IC1704 PIC-47143SY IR DETECT UNIT
IC1921 STR-W5753A/F5 I C
IC1971 BA17809T I C
IC1972 BA17805T I C
