Symbol No. Part No. Part Name Description
OTHERS
LC30114-001C-H LED HOLDER
CM35921-B02 CDS HOLDER
!
CP1981 ICP-N25-Y IC PROTECTOR
!
CP1982 ICP-N75-Y IC PROTECTOR
! F1901 QMF51E2-3R15J4 FUSE 3.15A
FC1901 CEMG002-001Z FUSE CLIP
FR1557 QRJ146J-2R2X C R 2.2
Ω
1/4W J
J1002 QNN0384-001 PIN JACK
J1003 QNN0281-003 PIN JACK or CEMN065-001
J1004 QNN0281-002 PIN JACK or CEMN065-002
!
J1005 QNS0197-001 3.5 JACK
K1351 QQR0621-002Z FERRITE BEADS
K1421 QQR1113-001Z FERRITE BEADS
K1901 QQR1113-001Z FERRITE BEADS
K1902 QQR1113-001Z FERRITE BEADS
K1941 QQR1113-001Z FERRITE BEADS
K1942 QQR1113-001Z FERRITE BEADS
K1943 QQR1113-001Z FERRITE BEADS
! LF1901 QQR0527-002 LINE FILTER
PC1701 P1241-04 PHOTO CONDUCTOR
S1701 QSW0619-003Z TACT SWITCH VOL+
S1702 QSW0619-003Z TACT SWITCH VOL-
S1703 QSW0619-003Z TACT SWITCH CH+
S1704 QSW0619-003Z TACT SWITCH CH-
S1705 QSW0619-003Z TACT SWITCH MENU
!
S1901 QSW0750-001 PUSH SWITCH POWER SW
SF1102 QAX0666-002 SAW FILTER
SF1122 QAX0325-001 SAW FILTER
! SK1351 QNZ0537-001 CRT SOCKET or QNZ0536-001
! TH1901 QAD0121-9R0 P THERMISTOR or QAD0119-9R0
!
TU1001 QAU0282-001 TUNER
!
VA1901 ERZV10V621CS ZNR or QAF0052-621
!
X1301 QAX0705-001Z CRYSTAL
X1302 CE41651-001Z X-TAL
X1701 QAX0307-001 C RESONATOR
