JVC AV-21F3 - Packing

No. 52024
A
V-21F
3
41
!
Symbol No. Part No. Part Name Description
OTHERS
LC30114-001C-H LED LED HOLDERR
!
CP1981 ICP-N25-Y I.C. PROTECT
!
CP1982 ICP-N75-Y I.C. PROTECT
! F1901 QMF51E2-3R15J4 FUSE 3.15A
FC1901 CEMG002-001Z FUSE CLIP (X2)
FR1557 QRJ146J-2R2X C R 2.2
Ω
1/4W J
J1002 QNN0384-001 PIN JACK
J1003 QNN0281-003 PIN JACK or CEMN065-001
J1004 QNN0281-002 PIN JACK or CEMN065-002
!
J1005 QNS0197-001 3.5 JACK
K1351 QQR0621-002Z BEADS CORE
K1421 QQR1113-001Z FERRITE BEADS
K1941 QQR1113-001Z FERRITE BEADS
K1942 QQR1113-001Z FERRITE BEADS
K1943 QQR1113-001Z FERRITE BEADS
!
LF1901 QQR0527-002 LINE FILTER
PC1701 P1241-04 C D S
S1701 QSW0619-003Z PUSH SWITCH VOL+
S1702 QSW0619-003Z PUSH SWITCH VOL-
S1703 QSW0619-003Z PUSH SWITCH CH+
S1704 QSW0619-003Z PUSH SWITCH CH-
S1705 QSW0619-003Z PUSH SWITCH MENU
! S1901 QSW0750-001 PUSH SWITCH POWER SW
SF1102 QAX0666-002 SAW FILTER
SF1122 QAX0325-001 SAW FILTER
!
SK1351 QNZ0537-001 CRT SOCKE or QNZ0536-001
!
TH1901 QAD0121-9R0 W POSISTOR or QAD0119-9R0
! TU1001 QAU0282-001 TUNER
! VA1901 ERZV10V621CS VARISTOR or QAF0052-621
!
X1301 QAX0705-001Z CRYSTAL
X1302 CE41651-001Z X-TAL
X1701 QAX0307-001 CERAMIC R
[ AV-21F3 ]
