No. 52024
A
V-21FR3
43
!
Symbol No. Part No. Part Name Description
RESISTOR
R1729 NRSA63J-102X MG R 1k
Ω
1/16W J
R1730 NRSA63J-103X MG R 10kΩ 1/16W J
R1731 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1736 NRSA63J-823X MG R 82kΩ 1/16W J
R1737 NRSA63J-104X MG R 100kΩ 1/16W J
R1738 NRSA63J-103X MG R 10kΩ 1/16W J
R1739 NRSA63J-103X MG R 10kΩ 1/16W J
R1740 NRSA63J-392X MG R 3.9kΩ 1/16W J
R1741 NRSA63J-561X MG R 560Ω 1/16W J
R1742 NRSA63J-563X MG R 56kΩ 1/16W J
R1746 NRSA63J-103X MG R 10kΩ 1/16W J
R1747 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R1748 NRSA63J-101X MG R 100
Ω
1/16W J
R1749 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1771 NRSA63J-821X MG R 820Ω 1/16W J
R1772 NRSA63J-821X MG R 820Ω 1/16W J
R1791 NRSA63J-221X MG R 220Ω 1/16W J
R1792 NRSA63J-221X MG R 220Ω 1/16W J
R1793 NRSA63J-221X MG R 220
Ω
1/16W J
R1794 NRSA63J-221X MG R 220Ω 1/16W J
R1795 NRSA63J-221X MG R 220Ω 1/16W J
R1796 NRSA63J-103X MG R 10kΩ 1/16W J
R1797 NRSA63J-153X MG R 15kΩ 1/16W J
R1802 NRSA63J-750X MG R 75Ω 1/16W J
R1806 QRE121J-271Y C R 270
Ω
1/2W J
R1807 NRSA63J-680X MG R 68Ω 1/16W J
R1810 QRG01GJ-560 OM R 56Ω 1W J
R1811 NRSA63J-221X MG R 220Ω 1/16W J
R1815 QRE121J-181Y C R 180Ω 1/2W J
R1816 NRSA63J-681X MG R 680Ω 1/16W J
R1817 NRSA63J-472X MG R 4.7k
Ω
1/16W J
R1825 NRSA63J-221X MG R 220Ω 1/16W J
R1827 NRSA63J-102X MG R 1kΩ 1/16W J
R1828 NRSA63J-272X MG R 2.7kΩ 1/16W J
R1832 NRSA63J-221X MG R 220Ω 1/16W J
R1833 NRSA63J-822X MG R 8.2kΩ 1/16W J
R1834 NRSA63J-393X MG R 39k
Ω
1/16W J
R1835 NRSA63J-182X MG R 1.8kΩ 1/16W J
R1836 NRSA63J-473X MG R 47kΩ 1/16W J
R1837 NRSA63J-393X MG R 39kΩ 1/16W J
R1838 NRSA63J-103X MG R 10kΩ 1/16W J
R1841 NRSA63J-332X MG R 3.3kΩ 1/16W J
R1842 NRSA63J-223X MG R 22k
Ω
1/16W J
R1843 NRSA63J-471X MG R 470Ω 1/16W J
R1845 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1846 NRSA63J-103X MG R 10kΩ 1/16W J
R1848 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R1849 NRSA63J-153X MG R 15kΩ 1/16W J
R1850 NRSA63J-332X MG R 3.3k
Ω
1/16W J
R1851 NRSA63J-821X MG R 820Ω 1/16W J
R1852 NRSA63J-332X MG R 3.3kΩ 1/16W J
R1853 NRSA63J-821X MG R 820Ω 1/16W J
R1854 NRSA63J-332X MG R 3.3kΩ 1/16W J
R1855 NRSA63J-821X MG R 820Ω 1/16W J
R1857 NRSA63J-103X MG R 10k
Ω
1/16W J
R1859 NRSA63J-473X MG R 47kΩ 1/16W J
R1860 NRSA63J-101X MG R 100Ω 1/16W J
R1861 NRSA63J-103X MG R 10kΩ 1/16W J
R1862 NRSA63J-391X MG R 390Ω 1/16W J
R1901 QRF104K-3R9 UNF R 3.9
Ω
10W K
R1903 QRL029J-104 OM R 100k
Ω
2W J
R1904 QRL039J-151 OM R 150Ω 3W J
R1906 QRL029J-104 OM R 100kΩ 2W J
R1921 QRE121J-2R2Y C R 2.2Ω 1/2W J
R1922 QRE121J-221Y C R 220Ω 1/2W J
R1923 QRM034J-R22 MP R 0.22
Ω
3W J
R1928 QRL039J-683 OM R 68k
Ω
3W J
R1933 QRE121J-4R7Y C R 4.7Ω 1/2W J
R1934 NRSA63J-683X MG R 68kΩ 1/16W J
R1935 QRE121J-562Y C R 5.6kΩ 1/2W J
R1974 NRSA63J-222X MG R 2.2kΩ 1/16W J
R1976 QRT029J-8R2 MF R 8.2
Ω
2W J
R1977 QRE121J-122Y C R 1.2k
Ω
1/2W J
R1978 NRSA63J-473X MG R 47kΩ 1/16W J
R1979 QRL039J-220 OM R 22Ω 3W J
R1980 QRL029J-152 OM R 1.5kΩ 2W J
! R1991 QRZ9046-825Z C R 8.2MΩ 1/2W K
!
Symbol No. Part No. Part Name Description
CAPACITOR
C1001 QETN1HM-106Z E CAP. 10
µ
F 50V M
C1002 NCB31HK-103X C CAP. 0.01µF 50V K
C1004 QETN1CM-477Z E CAP. 470µF 16V M
C1005 QFV71HJ-104Z MF CAP. 0.1µF 50V J
C1008 QETN1HM-475Z E CAP. 4.7µF 50V M
C1103 QETN1EM-476Z E CAP. 47µF 25V M
C1104 NCB31HK-472X C CAP. 4700pF 50V K
C1105 NCB31HK-472X C CAP. 4700pF 50V K
C1106 NCB31HK-472X C CAP. 4700pF 50V K
C1107 NCB31HK-472X C CAP. 4700pF 50V K
C1110 NRSA63J-0R0X MG R 0.0
Ω
1/16W J
C1112 QETN1EM-476Z E CAP. 47µF 25V M
C1113 NCB31HK-472X C CAP. 4700pF 50V K
C1114 NCB31HK-103X C CAP. 0.01µF 50V K
C1115 NCB31HK-103X C CAP. 0.01µF 50V K
C1116 NCB31HK-103X C CAP. 0.01µF 50V K
C1117 QFV71HJ-224Z MF CAP. 0.22µF 50V J
C1119 QETN1HM-474Z E CAP. 0.47
µ
F 50V M
C1120 NDC31HJ-121X C CAP. 120pF 50V J
C1121 NCB31HK-103X C CAP. 0.01
µ
F 50V K
C1122 NCB31HK-103X C CAP. 0.01
µ
F 50V K
C1162 NCB31HK-152X C CAP. 1500pF 50V K
C1301 NCB31HK-123X C CAP. 0.012
µ
F 50V K
C1302 QETN1HM-475Z E CAP. 4.7µF 50V M
C1303 NDC31HJ-100X C CAP. 10pF 50V J
C1304 QFV71HJ-474Z MF CAP. 0.47µF 50V J
C1305 QETN1HM-474Z E CAP. 0.47µF 50V M
C1306 NCB31HK-103X C CAP. 0.01µF 50V K
C1307 QETN1CM-477Z E CAP. 470µF 16V M
C1308 QETN1CM-107Z E CAP. 100µF 16V M
C1309 NCB31HK-103X C CAP. 0.01µF 50V K
C1310 NDC31HJ-221X C CAP. 220pF 50V J
C1311 NCB31HK-103X C CAP. 0.01
µ
F 50V K
C1312 QENC1HM-474Z E CAP. 0.47µF 50V M
C1313 QETN1HM-335Z E CAP. 3.3µF 50V M
C1314 NCB31HK-103X C CAP. 0.01µF 50V K
C1315 QETN1CM-107Z E CAP. 100µF 16V M
C1316 QETN1HM-106Z E CAP. 10
µ
F 50V M
C1317 NCB31EK-473X C CAP. 0.047
µ
F 25V K
C1321 NDC31HJ-120X C CAP. 12pF 50V J
C1322 NCB31EK-273X C CAP. 0.027
µ
F 25V K
C1323 QETN1HM-474Z E CAP. 0.47µF 50V M
C1324 QETN1HM-106Z E CAP. 10µF 50V M
C1325 QENC1HM-106Z BP E CAP. 10µF 50V M
C1326 NCS21HJ-221X C CAP. 220pF 50V J
C1341 QETN1HM-106Z E CAP. 10µF 50V M
C1352 QFZ0097-103 MM CAP. 0.01µF 1250V K
C1354 NDC31HJ-271X C CAP. 270pF 50V J
C1355 NDC31HJ-221X C CAP. 220pF 50V J
C1356 NDC31HJ-331X C CAP. 330pF 50V J
C1357 QETN1AM-477Z E CAP. 470µF 10V M
C1365 QENC1HM-105Z E CAP. 1µF 50V M
C1366 QENC1HM-105Z E CAP. 1µF 50V M
C1367 QENC1HM-105Z E CAP. 1µF 50V M
C1401 QFV71HJ-474Z MF CAP. 0.47
µ
F 50V J
C1423 QCS32HJ-180Z C CAP. 18pF 500V J
C1424 QFLC2AJ-103Z M CAP. 0.01
µ
F 100V J
C1426 QFLC1HJ-102Z M CAP. 1000pF 50V J
C1427 QETN1VM-107Z E CAP. 100µF 35V M
C1428 QETN1VM-107Z E CAP. 100µF 35V M
C1429 QETN1HM-106Z E CAP. 10µF 50V M
C1430 QFN32AJ-472Z M CAP. 4700pF 100V J
C1433 QETN1HM-475Z E CAP. 4.7µF 50V M
C1435 QETM1EM-228 E CAP. 2200µF 25V M
C1436 QFV71HJ-334Z MF CAP. 0.33µF 50V J
C1437 NCB31HK-104X C CAP. 0.1µF 50V K
C1501 QETN1AM-477Z E CAP. 470
µ
F 10V M
C1502 NCB31HK-103X C CAP. 0.01
µ
F 50V K
C1503 QETN1HM-106Z E CAP. 10µF 50V M
C1523 QETN1EM-476Z E CAP. 47µF 25V M
! C1525 QFZ0200-942 MPP CAP. 9400pF1.5kVH ± 3%
C1526 QFLC1HJ-103Z M CAP. 0.01µF 50V J
! C1527 QFZ0199-374 MPP CAP. 0.37µF 250V J
C1529 QFN32AJ-102Z M CAP. 1000pF 100V J
C1531 QEZ0203-107 E CAP. 100µF 160V M
C1552 QETM1VM-108 E CAP. 1000µF 35V M
C1554 QETN2EM-475Z E CAP. 4.7µF 250V M
C1555 QFLC2AJ-104Z M CAP. 0.1
µ
F 100V J
[ AV-21FR3 ]
