No. 52024
A
V-21FMG3B
49
!
Symbol No. Part No. Part Name Description
IC
IC1301 NN5198K I C
IC1421 AN5522 I C
IC1651 AN5265 I C
!
IC1701 MN1873287JJ1 I C(MCU)
IC1702 AT24C08-21DMG3 I C (SERVICE)
IC1703 L78LR05E-MA I C
IC1704 PIC-47143SY IR DETECT UNIT
!
IC1921 STR-W5753A/F5 I C
IC1971 BA17809T I C
IC1972 BA17805T I C
OTHERS
LC30114-001C-H LED HOLDER
CM35921-005-H CDS HOLDER
CF1161 QAX0642-001Z C FILTER
!
CP1981 ICP-N25-Y I.C.PROTECT
!
CP1982 ICP-N75-Y I.C.PROTECT
!
F1901 QMF51E2-3R15J4 FUSE 3.15A
FC1901 CEMG002-001Z FUSE CLIP (X2)
FR1557 QRJ146J-2R2X C R 2.2
Ω
1/4W J
J1002 QNN0384-001 PIN JACK or CEMN065-001
J1003 QNN0281-003 PIN JACK or CEMN065-002
J1004 QNN0281-002 PIN JACK
!
J1005 QNS0197-001 3.5 JACK
K1351 QQR0621-002Z FERRITE BEADS
K1421 QQR1113-001Z FERRITE BEADS
K1941 QQR1113-001Z FERRITE BEADS
K1942 QQR1113-001Z FERRITE BEADS
K1943 QQR1113-001Z FERRITE BEADS
!
LF1901 QQR0527-002 LINE FILTER
PC1701 P1241-04 PHOTO CONDUCTOR
S1701 QSW0619-003Z TACT SWITCH VOL+
S1702 QSW0619-003Z TACT SWITCH VOL-
S1703 QSW0619-003Z TACT SWITCH CH+
S1704 QSW0619-003Z TACT SWITCH CH-
S1705 QSW0619-003Z TACT SWITCH MENU
! S1901 QSW0750-001 PUSH SWITCH POWER SW
SF1102 QAX0731-001 SAW FILTER
SF1122 QAX0325-001 SAW FILTER
!
SK1351 QNZ0537-001 CRT SOCKET or QNZ0536-001
!
TH1901 QAD0121-9R0 THERMISTOR or QAD0119-9R0
! TU1001 QAU0282-001 TUNER
! VA1901 ERZV10V621CS VARISTOR or QAF0052-621
! X1301 QAX0705-001Z CRYSTAL
X1302 CE41651-001Z X-TAL
X1701 QAX0307-001 C RESONATOR
[ AV-21FMG3B]
