JVC CA-NXG9 Instructions

(MB685-R002) 5
Part No.
!
Symbol o
r
<Rev.001> <Rev.002>
Part Name Description Qty Models
M1 59 ------------ GV10430-021A REAR
PANEL
(Addition) 1 17
M1 59 ------------ GV10430-029A REAR
PANEL
(Addition) 1 18
M1 59 ------------ GV10430-010A REAR
PANEL
(Addition) 1 19
M1 59 ------------ GV10430-012A REAR
PANEL
(Addition) 1 1A
M1 59 ------------ GV10430-009A REAR
PANEL
(Addition) 1 1E
M1 61 ------------ QAU0510-001 TUNER (Addition) 1 19,1F
M1 87 ------------ QUQU12-1512BJ-E FFC WIRE (Addition) 1 19,1F
M1 97 ------------ GV30349-048A SPACER (Addition) 1 06,07,08,09,0D,0E,0F,10,11,12
M1 97 GV30349-048A ------------ SPACER (Deletion) 1 06,07,08,09,0D,0E,0F,10,11
M1 102 ------------ GV40839-001A IC SHEET (Addition) 1 0A,0B,0C,0D,0E,0F,10,11,12,19,1A,1B,1C,1D,
1E,1F,20,21
M1 102 GV40839-001A ------------ IC SHEET (Deletion) 1 0A,0D,0E,0F,10,11,12
M1 103 ------------ GV40794-001A TIS LABEL (Addition) 1 15,1E
M1 104 ------------ GN40099-001A CCC LABEL (Addition) 1 17
M1 105 ------------ GV31164-011A UF LABEL (Addition) 1 17
M1 106 ------------ GV40869-001A IMPEDANCE
LABEL
(Addition) 1 17
M1 107 ------------ QYSBSGY3008EA TAP SCREW (Addition) 2 19
M1 108 ------------ GV30759-027A UT RATING
LABEL
(Addition) 1 1C
M1 108 ------------ GV30830-021A UP LABEL (Addition) 1 1F
M1 108 ------------ GV30759-026A UT RATING
LABEL
(Addition) 1 20
M1 109 ------------ QYSBST3006EA TAP SCREW (Addition) 1 0A,0B,0C,0D,0E,0F,10,11,12,19,1A,1B,1C,1D,
1E,1F,20,21
Packing and accessories NX-G9/7 series [M3]
Part No.
!
Symbol or
<Rev.001> <Rev.002>
Part Name Description Qty Models
M3 A2 ------------ GVT0268-004A BLUETOOTH SHEET (Addition) 1 13
M3 A2 ------------ GVT0268-005A BLUETOOTH SHEET (Addition) 1 15
M3 A3 ------------ GVT0260-011A INST BOOK (Addition) 1 13
M3 A3 ------------ GVT0260-008A INST BOOK (Addition) 1 15
M3 A3 ------------ GVT0259-010A INST BOOK (Addition) 1 16
M3 A3 ------------ GVT0259-005A INST BOOK (Addition) 1 17
M3 A5 ------------ ------------ WARRANTY CARD (Addition) 1 13,16
M3 A19 ------------ GVT0273-001A DEMO CLEAR SHT (Addition) 1 14,18
M3 A20 ------------ LV44927-201A RECYCLE LABEL (Addition) 2 17
M3 A21 ------------ LV44928-201A RECYCLE MARK (Addition) 1 17
M3 P1 ------------ GV31223-004A CARTON (Addition) 1 13
M3 P1 ------------ GV31222-005A CARTON (Addition) 1 16
M3 P1 ------------ GV31222-006A CARTON (Addition) 1 17
Packing and accessories NX-G5/3 series [M4]
Part No.
!
Symbol or
<Rev.001> <Rev.002>
Part Name Description Qty Models
M4 A2 ------------ GVT0268-001A BLUETOOTH SHEET (Addition) 1 19
M4 A2 ------------ GVT0268-005A BT INFO SHEET (Addition) 1 1C,1E
M4 A3 ------------ GVT0260-009A INST BOOK (Addition) 1 19
M4 A3 ------------ GVT0260-005A INST BOOK (Addition) 1 1C
M4 A3 ------------ GVT0260-008A INST BOOK (Addition) 1 1E
M4 A3 ------------ GVT0259-008A INST BOOK (Addition) 1 1F
M4 A3 ------------ GVT0259-006A INST BOOK (Addition) 1 20
M4 A5 ------------ ------------ WARRANTY CARD (Addition) 1 19
M4 A5 ------------ ------------ WARRANTY CARD (Addition) 1 1F
M4 A8 ------------ GV30024-070A UB SHEET (Addition) 1 1B
M4 A11 ------------ RM-SNXG5R REMOCON (Addition) 1 19
M4 A15 ------------ QQR1834-001 NOISE FILTER (Addition) 2 19,20
M4 A19 ------------ GVT0273-001A DEMO CLEAR SHT (Addition) 1 1D,21
M4 A22 ------------ QQR1804-001 FERRITE RING (Addition) 1 20
M4 P1 ------------ GV31221-004A CARTON (Addition) 1 19
