Electrical parts list Primary board NX-G9A,US,UY,UG,UN/NX-G7A,US,UG,UN [01]
Part No.
!
Symbol or
<Rev.001> <Rev.002>
Part Name Description Qty Models
01 Q170 ------------ KRC111S-X TRANSISTOR (Addition) 1 13,14,15,16,17,18
01 C114 ------------ NDC31HJ-331X C CAPACITOR (Addition) 1 13,14,15,16,17,18
01 C2700 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 13,14,15,16,17,18
01 C2702 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 13,14,15,16,17,18
01 C2704 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 13,14,15,16,17,18
01 C2706 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 13,14,15,16,17,18
01 C2810 ------------ NCB31AK-105X C CAPACITOR (Addition) 1 13,14,15,16,17,18
01 C2812 ------------ NCB31AK-105X C CAPACITOR (Addition) 1 13,14,15,16,17,18
01 C2814 ------------ NCB31AK-105X C CAPACITOR (Addition) 1 13,14,15,16,17,18
01 C8810 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 13,14,15
01 R8700 ------------ NRSA63J-201X MG RESISTOR (Addition) 1 16,17,18
01 R8701 ------------ NRSA63J-201X MG RESISTOR (Addition) 1 13,14,15
01 L150 ------------ QQLZ043-220 COIL (Addition) 1 13,14,15,16,17,18
01 L170 ------------ QQL94AM-220 CHOKE COIL (Addition) 1 13,14,15,16,17,18
01 L8300 ------------ QQL94AM-220 CHOKE COIL (Addition) 1 13,14,15,16,17,18
01 L8800 ------------ QQL94AM-220 CHOKE COIL (Addition) 1 13,14,15
01 CN805 ------------ QGF1036F2-13 CONNECTOR (Addition) 1 13,14,15
01 CN808 ------------ QGF1036F2-27 CONNECTOR (Addition) 1 13,14,15
01 CN808 ------------ QGF1036F2-25 CONNECTOR (Addition) 1 16,17,18
01 CN809 ------------ QGF1036F2-13 CONNECTOR (Addition) 1 13,14,15
01 CN810 ------------ QGF1036C2-05 CONNECTOR (Addition) 1 13,14,15,16,17,18
01 CN815 ------------ QGF1036F2-05 CONNECTOR (Addition) 1 16,17,18
01 CN920 ------------ QGF1036F2-07 CONNECTOR (Addition) 1 13,14,15,16,17,18
01 CN940 ------------ QGF1036F2-07 CONNECTOR (Addition) 1 13,14,15,16,17,18
Primary board NX-G5US,UG,UN/NX-G3A,US,UB,UG,UN,UH [02]
Part No.
!
Symbol o
r
<Rev.001> <Rev.002>
Part Name Description Qty Models
02 Q2306 ------------ KRC102S-X DIGI TRANSISTOR (Addition) 1 19
02 Q2307 ------------ KRC102S-X DIGI TRANSISTOR (Addition) 1 19
02 Q2308 ------------ KRA102S-X DIGI TRANSISTOR (Addition) 1 19
02 Q2309 ------------ KRC102S-X DIGI TRANSISTOR (Addition) 1 19
02 C102 ------------ QCZ9134-101 C CAPACITOR (Addition) 1 1C,20
02 C104 ------------ QCZ9134-101 C CAPACITOR (Addition) 1 1C,20
02 C114 ------------ NDC31HJ-331X C CAPACITOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 C176 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 20
02 C180 ------------ QFVF1HJ-105Z MF CAPACITOR (Addition) 1 19
02 C2007 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 19
02 C2011 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 19
02 C2015 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 19
02 C2019 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 19
02 C2020 ------------ NDC31HJ-331X C CAPACITOR (Addition) 1 19
02 C2021 ------------ NDC31HJ-331X C CAPACITOR (Addition) 1 19
02 C2700 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 C2702 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 C2704 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 C2706 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 C2810 ------------ NCB31AK-105X C CAPACITOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 C2812 ------------ NCB31AK-105X C CAPACITOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 C2814 ------------ NCB31AK-105X C CAPACITOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 C8306 ------------ NCB31CK-105X C CAPACITOR (Addition) 1 20
02 C8310 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 20
02 C8810 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 19,1A,1B,1C,1D,1E
02 C8812 ------------ NCB31CK-104X C CAPACITOR (Addition) 1 19,1F,20
02 R176 ------------ NRSA02J-100X MG RESISTOR (Addition) 1 20
02 R2001 ------------ NRSA63J-750X MG RESISTOR (Addition) 1 19
02 R2003 ------------ NRSA63J-750X MG RESISTOR (Addition) 1 19
02 R2007 ------------ NRSA63J-750X MG RESISTOR (Addition) 1 19
02 R2011 ------------ NRSA63J-750X MG RESISTOR (Addition) 1 19
02 R2015 ------------ NRSA63J-750X MG RESISTOR (Addition) 1 19
02 R2016 ------------ NRSA63J-101X MG RESISTOR (Addition) 1 19
02 R2017 ------------ NRSA63J-104X MG RESISTOR (Addition) 1 19
02 R2019 ------------ NRSA63J-750X MG RESISTOR (Addition) 1 19
02 R2022 ------------ NRSA63J-303X MG RESISTOR (Addition) 1 19
02 R2023 ------------ NRSA63J-303X MG RESISTOR (Addition) 1 19
02 R2024 ------------ NRSA63J-393X MG RESISTOR (Addition) 1 19
