JVC CA-NXG9 Instructions

(MB685-R002) 7
Part No.
!
Symbol o
r
<Rev.001> <Rev.002>
Part Name Description Qty Models
02 R2025 ------------ NRSA63J-393X MG RESISTOR (Addition) 1 19
02 R2305 ------------ NRSA63J-222X MG RESISTOR (Addition) 1 19
02 R2306 ------------ NRSA63J-152X MG RESISTOR (Addition) 1 19
02 R2307 ------------ NRSA63J-123X MG RESISTOR (Addition) 1 19
02 R8198 ------------ NRSA63J-103X MG RESISTOR (Addition) 1 19,1C,1F,20
02 R8199 ------------ NRSA63J-332X MG RESISTOR (Addition) 1 1C,1F,20
02 R8310 ------------ NRSA02J-100X MG RESISTOR (Addition) 1 20
02 R8700 ------------ NRSA63J-201X MG RESISTOR (Addition) 1 1F,20,21
02 R8701 ------------ NRSA63J-201X MG RESISTOR (Addition) 1 19,1A,1B,1C,1D,1E
02 L150 ------------ QQLZ043-220 COIL (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 L170 ------------ QQL94AM-220 CHOKE COIL (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 L8300 ------------ QQL94AM-220 CHOKE COIL (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 L8800 ------------ QQL94AM-220 CHOKE COIL (Addition) 1 19,1A,1B,1C,1D,1E
02 CN805 ------------ QGF1036F2-13 CONNECTOR (Addition) 1 19,1A,1B,1C,1D,1E
02 CN806 ------------ QGF1208F1-15 CONNECTOR (Addition) 1 19,1F
02 CN808 ------------ QGF1036F2-27 CONNECTOR (Addition) 1 19,1A,1B,1C,1D,1E
02 CN808 ------------ QGF1036F2-25 CONNECTOR (Addition) 1 1F,20,21
02 CN809 ------------ QGF1036F2-13 CONNECTOR (Addition) 1 19,1A,1B,1C,1D,1E
02 CN810 ------------ QGF1036C2-05 CONNECTOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 CN815 ------------ QGF1036F2-05 CONNECTOR (Addition) 1 1F,20,21
02 CN920 ------------ QGF1036F2-07 CONNECTOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 CN940 ------------ QGF1036F2-07 CONNECTOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
02 J2000 ------------ QNZ0775-001 RGB CONNECTOR (Addition) 1 19
Power board NX-G9/7 series [03]
Part No.
!
Symbol or
<Rev.001> <Rev.002>
Part Name Description Qty Models
03 C422 ------------ NDC31HJ-271X C CAPACITOR (Addition) 1 13,14,15
03 C422 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 16,17,18
03 C423 ------------ NDC31HJ-271X C CAPACITOR (Addition) 1 13,14,15
03 C423 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 16,17,18
03 C424 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 13,14,15,16,17,18
03 C425 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 13,14,15,16,17,18
03 C432 ------------ NDC31HJ-271X C CAPACITOR (Addition) 1 13,14,15
03 C432 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 16,17,18
03 C433 ------------ NDC31HJ-271X C CAPACITOR (Addition) 1 13,14,15
03 C433 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 16,17,18
03 C434 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 13,14,15,16,17,18
03 C435 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 13,14,15,16,17,18
03 C451 ------------ NCB31AK-105X C CAPACITOR (Addition) 1 13,14,15,16,17,18
03 C452 ------------ NDC31HJ-221X C CAPACITOR (Addition) 1 13,14,15,16,17,18
03 C9503 ------------ NDC31HJ-271X C CAPACITOR (Addition) 1 13,14,15,16,17,18
03 C9512 ------------ NCB31AK-105X C CAPACITOR (Addition) 1 13,14,15,16,17,18
03 C9801 ------------ QETN1AM-477Z E CAPACITOR (Addition) 1 13,14,15
03 R411 ------------ NRSA63J-562X MG RESISTOR (Addition) 1 13,14,15,16,17,18
03 CN300 ------------ QGF1036C2-05 CONNECTOR (Addition) 1 13,14,15,16,17,18
03 CN301 ------------ QGF1036C2-07 CONNECTOR (Addition) 1 13,14,15
Power board NX-G5/3 series [04]
Part No.
!
Symbol o
r
<Rev.001> <Rev.002>
Part Name Description Qty Models
04 C5106 ------------ NCB31HK-103X C CAPACITOR (Addition) 1 19,1F,20
04 C5108 ------------ NCB31HK-102X C CAPACITOR (Addition) 1 19,1F,20
04 C5109 ------------ NCB31HK-102X C CAPACITOR (Addition) 1 19,1F,20
04 C5200 ------------ NCB31HK-103X C CAPACITOR (Addition) 1 1F,20
04 C5220 ------------ NCB31HK-103X C CAPACITOR (Addition) 1 19,1F,20
04 C5230 ------------ NCB31HK-103X C CAPACITOR (Addition) 1 19,1F,20
04 C5304 ------------ NCB31CK-104X C CAPACITOR (Addition) 1 20
04 C6521 ------------ QETN1EM-476Z E CAPACITOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
04 C7115 ------------ NCB11EK-105X C CAPACITOR (Addition) 1 1C,20
04 C7125 ------------ NCB11EK-105X C CAPACITOR (Addition) 1 1C,20
04 C7215 ------------ NCB11EK-105X C CAPACITOR (Addition) 1 1C,20
04 C7225 ------------ NCB11EK-105X C CAPACITOR (Addition) 1 1C,20
04 CN610 ------------ QGF1036C2-05 CONNECTOR (Addition) 1 19,1A,1B,1C,1D,1E,1F,20,21
04 CN630 ------------ QGF1036C2-07 CONNECTOR (Addition) 1 19,1A,1B,1C,1D,1E
04 SP700 GV40839-001A ------------ IC SHEET (Deletion) 1 0B,0C
