CH-X1500
1-11
2.4.8 Remove the lifter bracket (See fig.21)
(1) Remove the two screws K attaching the lifter bracket from
the back of the lifter unit.
(2) Remove the lower rod.
Fig.21
2.4.9 Remove the side bracket and traverse mechanism assenbly (See fig.22)
(1) Remove the two screws L attaching the side bracket, and
remove the side bracket.
(2) Remove the three shafts on the traverse mechanism as-
sembly from the lifter unit.
Fig.22
K
K
Lifter bracket
Lifter unit
Traverse mechanism
assembly
Side bracket
L
L
