JVC Colour Video Monitor TM-A140E User Manual

14
368.5
363.5
1.5
5
3.5
63.7
273
346
284
310
287
*
*
217
TM-A140E
PHASE CHROMA BRIGHT CONTRAST MENU
INPUT SELECT
VOLUME/SELECT
–
+
B A
POWER
ON
OFF
7 Dimensions Unit : mm
< Front View >
< Side View >
7 Y/C (Mini DIN 4 pin) terminal specifi cation
Pin No. Signal
1 GND (Y)
2 GND (C)
3Y
4C
3
1
4
2
Y/C IN
* Asterisks (
∗
) are used to indicate front panel
dimensions.
02-15EN_TM-A140E_f.indd 1402-15EN_TM-A140E_f.indd 14 06.6.8 7:53:32 PM06.6.8 7:53:32 PM
