Preparation
2
No.
Designation
Resolution
fh
[kHz]
fv
[Hz]
dot CLK
[MHz]
Total No.
of dots
[dot]
Total No.
of lines
[line]
No. of
effective
dots
[dot]
No. of
effective
lines [line]
1
VGA
60 640 X 480 31.500 60.000 25.200 800 525 640 480
2
VGA
59.94 640 X 480 31.469 59.940 25.175 800 525 640 480
3
SVGA
60 800 X 600 37.879 60.317 40.000 1,056 628 800 600
4
XGA
60
1024 X 768 48.363
60.004 65.000
1,344
806 1,024
768
5
WXGA
60
1280 X 768 47.760
60.000
79.998 1,675
796 1,280
768
6
WXGA
+60 1440 X 900 55.919 59.999 106.470 1,904 932 1,440 900
7
SXGA
60 1280 X 1024 63.981 60.020 108.000 1,688 1,066 1,280 1,024
8
WSXGA
+60 1680 X 1050 65.222 60.002 147.140 2,256 1,087 1,680 1,050
9
WUXGA
60 1920 X 1200 74.038 59.95 154.000 2,080 1,235 1,920 1,200
About the connection
Types of possible input signals
Analog Video Input Format
signals
480i, 480p, 576i, 576p, 720p/50Hz, 720p/60Hz,
1080i/50Hz, 1080i/60Hz
Digital Video Input Format
signals
480i, 480p, 576i, 576p, 720p/50Hz, 720p/60Hz,
1080i/50Hz, 1080i/60Hz,1080p/24Hz,
1080p/50Hz, 1080p/60Hz
3D
signal
frame pack method
720p/50Hz, 720p/60Hz, 1080p/24Hz, 1080i/50Hz, 1080i/60Hz
side by side method
1080i/60Hz, 1080p/60Hz, 1080i/50Hz, 1080p/50Hz, 1080p/24Hz,
720p/50Hz, 720p/60Hz
top and down method
720p/50Hz, 720p/60Hz, 1080p/24Hz
●
PC signal (HDMI)
