1-2 (No.YD075)
SPECIFICATION
• Specifications shown are for SP mode unless otherwise specified.
• E.& O.E. Design and specifications subject to change without notice.
• Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
• "DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems, Inc.
• VIDEO Plus+ and PlusCode are registered trademarks of Gemstar Development Corporation. The VIDEO Plus+ system is manufactured under
license from Gemstar Development Corporation.
• (i.Link) refers to the IEEE1394-1995 industry specification and extensions thereof. The logo is used for products compliant with the i.Link stan-
dard.
GENERAL
Power requirement AC 220 V - 240V, 50/60 Hz
Power consumption
Power on 38W
Power off 7.0W
Temperature
Operating 5°C to 35°C
Storage -20°C to 60°C
Operating position Horizontal only
Dimensions (W × H × D) 435 mm x 96 mm x 344 mm
Weight 5.8 kg
Input/Output
Video input
1.0 Vp-p, 75 Ω (pin jack)
Audio input
-8 dB, 50 kΩ (pin jack), Corresponding to mono (left)
Audio output -8 dB, 1 kΩ (pin jack)
21-pin SCART connectors IN/OUT x 1, IN/DECODER x 1
Input/Output (DVD Deck Only)
S-video input Y: 1.0 Vp-p, 75 Ω, C: 0.300 Vp-p, 75 Ω
i.Link 4-pin for DV input
Component video output Y: 1.0 Vp-p, 75 Ω, CB/CR, PB/PR: 0.7 Vp-p, 75 Ω
Corresponding to copy protection
Digital audio output Coaxial, Corresponding to Dolby Digital and DTS Digital Surround
Bit stream Selectable in digital audio output setting menu
VIDEO/AUDIO (DVD deck)
Recording time Maximum 8 hours (with 4.7 GB disc)
(XP): Approx. 1 hour, (SP): Approx. 2 hours, (LP): Approx. 4 hours
(EP): Approx. 6 hours, (FR): Approx. 1 hour - 8 hours
Audio recording system Dolby Digital (2 ch), Linear PCM (XP mode only)
Video recording compression system MPEG2 (CBR/VBR)
VIDEO/AUDIO (VHS Deck)
Signal system PAL colour signal and CCIR monochrome signal, 625 lines/50 fields
Recording system DA4 (Double Azimuth) head helical scan system
Format VHS PAL standard
Maximum recording time
(SP) 180 min. with E-180 video cassette
(LP) 360 min. with E-180 video cassette
Signal-to-noise ratio 45 dB
Horizontal resolution 230 lines
Frequency range 70 Hz to 10,000 Hz (Normal audio) 20 Hz to 20,000 Hz (Hi-Fi audio)
TUNER/TIMER
TV channel storage capacity 99 positions (+AUX position)
Tuning system Frequency synthesized tuner
Channel coverage VHF 47 MHz - 143 MHz/143 MHz - 470 MHz, UHF 470 MHz - 862 MHz
Memory backup time Approx. 10 minutes
ACCESSORIES
Provided accessories RF cable, 21-pin SCART cable, Infrared remote control unit, "AA" battery x 2
