JVC EX-A5 User Manual

3-15
Micom board
Block No. [0][2]
WC201 QZW0112-002 WIRE CLAMP
 Symbol No. Part No. Part Name Description Local
IC401 NJM4565M-W IC
IC601 MM1623XF-X IC
IC602 SN74AHCT08NS-X IC
IC603 SN74LVC08ANS-X IC
IC611 GP1FAV30TK0F OPT TRANSMITTER
IC701 UPD784217AGF546 IC(ROM MICOM)
IC711 BR24L02F-W-X IC
IC751 LB1641 IC
IC761 SAA6588T/V2-X IC
Q4101 2SC3661-X TRANSISTOR
Q4102 2SC3661-X TRANSISTOR
Q4201 2SC3661-X TRANSISTOR
Q4202 2SC3661-X TRANSISTOR
Q4301 UN211L-X TRANSISTOR
Q6052 UN2214-X TRANSISTOR
Q6053 UN2113-X DIGI TRANSISTOR
Q6054 UN2214-X TRANSISTOR
Q7301 2SA1530A/QR/-X TRANSISTOR
Q7302 2SC3928A/QR/-X TRANSISTOR
Q7401 UN2214-X TRANSISTOR
Q7511 UN2213-X DIGI TRANSISTOR
Q7512 UN2213-X DIGI TRANSISTOR
Q7513 UN2213-X DIGI TRANSISTOR
Q7514 2SA1530A/QR/-X TRANSISTOR
Q7601 UN2111-X TRANSISTOR
Q7602 UN2211-X TRANSISTOR
Q7701 UN2111-X TRANSISTOR
Q7702 2SD601A/RS/-X TRANSISTOR
Q7712 UN2211-X TRANSISTOR
Q7713 2SC3928A/QR/-X TRANSISTOR
Q7801 KTC3195/O/-T TRANSISTOR
Q7802 KTC3195/O/-T TRANSISTOR
D6091 MTZJ6.2C-T2 Z DIODE
D7001 MA111-X SI DIODE
D7301 1SS133-T2 SI DIODE
D7302 MTZJ5.1B-T2 Z DIODE
D7401 1SS133-T2 SI DIODE
D7701 1SS133-T2 SI DIODE
D7702 MTZJ10B-T2 Z DIODE
D7703 MTZJ8.2B-T2 Z DIODE
D7711 1SS133-T2 SI DIODE
D7713 1SS133-T2 SI DIODE
D7715 1SS133-T2 SI DIODE
D7716 1SS133-T2 SI DIODE
D7717 RB521S-30-X SB DIODE
C1181 NCS31HJ-221X C CAPACITOR 220pF 50V J
C1181 NCB31HK-221X C CAPACITOR 220pF 50V K
C1182 NCB31EK-332X C CAPACITOR 3300pF 25V K
C1184 NCS31HJ-221X C CAPACITOR 220pF 50V J
C1184 NCB31HK-221X C CAPACITOR 220pF 50V K
C1281 NCS31HJ-221X C CAPACITOR 220pF 50V J
C1281 NCB31HK-221X C CAPACITOR 220pF 50V K
C1282 NCB31EK-332X C CAPACITOR 3300pF 25V K
C1284 NCS31HJ-221X C CAPACITOR 220pF 50V J
C1284 NCB31HK-221X C CAPACITOR 220pF 50V K
C1381 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1381 NDC31HJ-101X C CAPACITOR 100pF 50V J
C4101 QEKC1AM-227Z E CAPACITOR 220uF 10V M
C4102 NCS31HJ-221X C CAPACITOR 220pF 50V J
C4103 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4104 QER61HM-475Z E CAPACITOR 4.7uF 50V M
C4106 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4201 QEKC1AM-227Z E CAPACITOR 220uF 10V M
C4202 NCS31HJ-221X C CAPACITOR 220pF 50V J
 Symbol No. Part No. Part Name Description Local
C4203 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4204 QER61HM-475Z E CAPACITOR 4.7uF 50V M
C4206 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4301 QETN1EM-476Z E CAPACITOR 47uF 25V M
C4302 QETN1CM-227Z E CAPACITOR 220uF 16V M
C4303 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C4304 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4305 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C6001 QETN1AM-477Z E CAPACITOR 470uF 10V M
C6002 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C6003 QFV61HJ-104Z MF CAPACITOR 0.1uF 50V J
C6004 QFV61HJ-104Z MF CAPACITOR 0.1uF 50V J
C6005 QFV61HJ-104Z MF CAPACITOR 0.1uF 50V J
C6006 QFV61HJ-104Z MF CAPACITOR 0.1uF 50V J
C6007 QFV61HJ-104Z MF CAPACITOR 0.1uF 50V J
C6008 QER61EM-226Z E CAPACITOR 22uF 25V M
C6011 QETN1EM-476Z E CAPACITOR 47uF 25V M
C6013 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C6014 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C6090 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6100 NCB31HK-221X C CAPACITOR 220pF 50V K
A5MK
2B,A5
MK2E
,A5M
K2EE,
A5MK
2EN
C6100 NCS31HJ-221X C CAPACITOR 220pF 50V J
C6101 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C7015 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7024 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7181 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
C7182 QER61CM-107Z E CAPACITOR 100uF 16V M
C7190 QETN1HM-105Z E CAPACITOR 1uF 50V M
C7191 QETN1HM-105Z E CAPACITOR 1uF 50V M
C7275 QER61HM-106Z E CAPACITOR 10uF 50V M
C7276 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7301 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7302 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7305 NCB31HK-822X C CAPACITOR 8200pF 50V K
C7306 NCB31HK-822X C CAPACITOR 8200pF 50V K
C7401 NCS31HJ-331X C CAPACITOR 330pF 50V J
C7509 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C7511 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
C7512 QETN1CM-337Z E CAPACITOR 330uF 16V M
C7513 QETN1CM-226Z E CAPACITOR 22uF 16V M
C7601 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7602 NCB31HK-561X C CAPACITOR 560pF 50V K
C7603 QER61HM-225Z E CAPACITOR 2.2uF 50V M
C7604 NCB31HK-331X C CAPACITOR 330pF 50V K
C7605 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7606 NCS31HJ-820X C CAPACITOR 82pF 50V J
C7607 NCS31HJ-470X C CAPACITOR 47pF 50V J
C7608 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C7701 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7703 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7711 QETN0JM-228Z E CAPACITOR 2200uF 6.3V M
C7712 QER61HM-225Z E CAPACITOR 2.2uF 50V M
C7801 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C7802 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C7803 NCS31HJ-390X C CAPACITOR 39pF 50V J
C7804 NCS31HJ-390X C CAPACITOR 39pF 50V J
C7805 NCS31HJ-330X C CAPACITOR 33pF 50V J
C7806 NCS31HJ-330X C CAPACITOR 33pF 50V J
R4101 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4102 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R4103 QRE141J-220Y C RESISTOR 22
Ω 1/4W J
R4105 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4106 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R4107 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R4110 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4111 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R4112 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R4201 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R4202 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R4203 QRE141J-220Y C RESISTOR 22
Ω 1/4W J
R4205 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4206 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
