1-8 (No.MB396)
SECTION 3
DISASSEMBLY
3.1 Main body section
3.1.1 Removing the top cover
(See Fig.1)
(1) From the top side of the main body, remove the four screws
A attaching the top cover.
Fig.1
A A
A
Top cover
