JVC EX-A5 User Manual

3-17
Digital amplifier board
Block No. [0][3]
CN707 QGF1205F1-21 CONNECTOR FFC/FPC (1-21)
EP601 QNZ0136-001Z EARTH PLATE
J3001 QNB0186-001 SPK TERMINAL
J4001 QNS0223-001 3.5 JACK
J6005 QNS0089-001 3.5 JACK
K4101 NQR0007-002X FERRITE BEADS
K4201 NQR0007-002X FERRITE BEADS
K4301 NQR0007-002X FERRITE BEADS
K6001 QQR0621-001Z COIL
K6011 QQR0621-001Z COIL
K6091 QQR0621-001Z COIL
K7038 QQR0621-001Z COIL
K7039 QQR0621-001Z COIL
K7275 QQR0621-001Z COIL
K7501 QQR0621-001Z COIL
K7601 QQR0621-001Z COIL
K7701 QQR0621-001Z COIL
WC101 QZW0112-002 WIRE CLAMP
X7601 QAX0263-001Z CRYSTAL 4.332MHz
X7801 QAX0416-001Z C RESONATOR 8.000MHz
 Symbol No. Part No. Part Name Description Local
IC111 NJM4580M-X IC
IC112 NJU7109F3-X IC
IC113 SN74AHC1G00V-X IC
IC121 NJM4580M-X IC
IC122 NJU7109F3-X IC
IC123 SN74AHC1G00V-X IC
IC131 NJM2115V-W IC
 IC132 STA506A-W IC
IC301 SN74HCU04ANS-X IC
IC302 SN74LV00ANS-X IC
 IC303 NJM78L05A-T IC
Q1101 UN211E-X DIGI TRANSISTOR
Q1102 UN211E-X DIGI TRANSISTOR
Q1103 2SC3661-X TRANSISTOR
Q1104 UMY1N-W TRANSISTOR
Q1201 UN211E-X DIGI TRANSISTOR
Q1202 UN211E-X DIGI TRANSISTOR
Q1203 2SC3661-X TRANSISTOR
Q1204 UMY1N-W TRANSISTOR
Q3002 KTA1267/YG/-T TRANSISTOR
Q3003 2SC3928A/QR/-X TRANSISTOR
Q3004 2SC3928A/QR/-X TRANSISTOR
Q3005 2SC3928A/QR/-X TRANSISTOR
Q3006 2SA1530A/QR/-X TRANSISTOR
Q3007 UN2112-X DIGI TRANSISTOR
D1104 MA152WK-X SI DIODE
D1203 UDZS6.8B-X Z DIODE
D3001 MA152WK-X SI DIODE
D3003 MA152WK-X SI DIODE
C1101 QTE1V06-106Z E CAPACITOR 10uF 35V
C1102 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1103 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1104 NCB31HK-471X C CAPACITOR 470pF 50V K
C1105 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C1106 QTE1V06-106Z E CAPACITOR 10uF 35V
C1107 NCB31HK-122X C CAPACITOR 1200pF 50V K
C1108 NCB31HK-331X C CAPACITOR 330pF 50V K
C1109 NCS31HJ-220X C CAPACITOR 22pF 50V J
C1110 NCS31HJ-220X C CAPACITOR 22pF 50V J
C1111 NCS31HJ-220X C CAPACITOR 22pF 50V J
C1113 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C1114 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1115 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1118 NCB21HK-104X C CAPACITOR 0.1uF 50V K
 Symbol No. Part No. Part Name Description Local
C1123 QTE1V06-106Z E CAPACITOR 10uF 35V
C1124 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1125 QFVF1HJ-684Z MF CAPACITOR 0.68uF 50V J
C1126 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1127 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1128 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1129 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1130 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1132 NCS31HJ-181X C CAPACITOR 180pF 50V J
C1133 NCB31HK-471X C CAPACITOR 470pF 50V K
C1134 NCB31HK-471X C CAPACITOR 470pF 50V K
C1137 NCB21CK-105X C CAPACITOR 1uF 16V K
C1140 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1141 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1142 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1143 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1144 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1201 QTE1V06-106Z E CAPACITOR 10uF 35V
C1202 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1203 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1204 NCB31HK-471X C CAPACITOR 470pF 50V K
C1205 QTE1H06-475Z E CAPACITOR 4.7uF 50V
C1206 QTE1V06-106Z E CAPACITOR 10uF 35V
C1207 NCB31HK-122X C CAPACITOR 1200pF 50V K
C1208 NCB31HK-331X C CAPACITOR 330pF 50V K
C1209 NCS31HJ-220X C CAPACITOR 22pF 50V J
C1210 NCS31HJ-220X C CAPACITOR 22pF 50V J
C1211 NCS31HJ-220X C CAPACITOR 22pF 50V J
C1213 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C1214 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1215 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1218 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1222 QTE1C06-336Z E CAPACITOR 33uF 16V
C1223 QTE1V06-106Z E CAPACITOR 10uF 35V
C1224 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1225 QFVF1HJ-684Z MF CAPACITOR 0.68uF 50V J
C1226 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1227 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1228 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1229 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1230 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1232 NCS31HJ-181X C CAPACITOR 180pF 50V J
C1233 NCB31HK-471X C CAPACITOR 470pF 50V K
C1234 NCB31HK-471X C CAPACITOR 470pF 50V K
C1237 NCB21CK-105X C CAPACITOR 1uF 16V K
C1240 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1241 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1242 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1243 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1244 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1301 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C1302 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1303 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1304 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1305 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C1306 NCB31EK-104X C CAPACITOR 0.1uF 25V K
 C1307 QTMN1EM-477Z E CAPACITOR 470uF 25V M
C1308 QTE1E06-226Z E CAPACITOR 22uF 25V
C1309 NFV41HJ-333X MPPS CAPACITOR 0.033uF 50V J
C1310 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3002 NDC31HJ-471X C CAPACITOR 470pF 50V J
C3003 NDC31HJ-471X C CAPACITOR 470pF 50V J
C3004 NDC31HJ-471X C CAPACITOR 470pF 50V J
C3005 NDC31HJ-471X C CAPACITOR 470pF 50V J
C3006 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C3007 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C3008 NCB31HK-331X C CAPACITOR 330pF 50V K
C3009 NCB31HK-331X C CAPACITOR 330pF 50V K
C3010 NCS31HJ-470X C CAPACITOR 47pF 50V J
C3011 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3012 QFVF1HJ-334Z MF CAPACITOR 0.33uF 50V J
C3013 QETN1EM-107Z E CAPACITOR 100uF 25V M
C3015 QER61HM-106Z E CAPACITOR 10uF 50V M
C3016 QER61HM-106Z E CAPACITOR 10uF 50V M
C3017 QER61HM-106Z E CAPACITOR 10uF 50V M
C3018 QER61HM-106Z E CAPACITOR 10uF 50V M
C3019 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C3020 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
 Symbol No. Part No. Part Name Description Local
