JVC FS-G6 Service Manual

3-3
UX-G6/FS-G6
Parts list (AX-UXG6 General assembly)
Item
Parts number Parts name
Area
Q'ty
Description
Block No
.
M1MM
1 LV10268-003A FRONT PANEL 1
2 LV41290-002A PUSH BUTTON 1 POWER PLATING
3 LV41291-002A PUSH BUTTON 1 OP/CL PLATING
4 LV41292-002A PUSH BUTTON 1 AUX PLATING
5 LV41293-002A PUSH BUTTON 1 BAND PLATING
6 LV41327-001A INDICATOR 1
7 LV31445-001A INDICATOR 2 FOR M.JOG/VOL
8 QYSBSF2608Z T.SCREW 2 FOR INDICATOR
9 E406971-222 JVC MARK 1
10 LV31437-002A FL LENS 1
11 LV40220-006A FILTER 1
12 QYSBSF2608Z T.SCREW 4 FOR SW PWB
13 LV10269-001A FRONT COVER 1
14 LV41302-001A COLLOR
(
B
)
2
15 QYSBSF2608M SCREW 7 FOR F.PANEL
16 LV10266-002A FRONT BASE 1
17 LV20519-001A EDIT BUTTON 1
18 QYSBSF2608Z T.SCREW 5 FOR MICON PWB
19 QYSBSF2608Z T.SCREW 4 FOR EDIT SW PWB
20 E75896-002 FELT SPACER 2 FOR FOOT
21 LV31444-001A JOG KNOB 2
22 QYSBST3006Z T.SCREW 2 FOR F.BASE+B.CHASSIS
23 LV31489-001A MOTOR BKT ASS'Y 1
26 LV41304-001A WORM WHEEL 1
27 QYREE2000X E RING 1
28 VYH8090-001SC GEAR 1 1
29 LV41303-001A PULLY 1
30 VKB3000-183 BELT 1
31 PWN10EB12A5 DC.MOTOR 1
32 QYSPSPT2020Z MINI SCREW 2 FOR MOTOR
33 QYSBST2005Z T.SCREW 1 FOR PWB+M.BKT
34 QYSBST3006Z T.SCREW 2 FOR B.CHAS+M.BK
35 QYSBST3006Z T.SCREW 2 FOR M.BKT+PWB
36 LV10289-001A B.CHASSIS ASS'Y 1
37 LV20518-001A ARM BRACKET 1
39 LV41301-001A COLLOR
(
A
)
4
40 QSW0874-001 SWITCH 1 SW912
41 LV41305-001A COLLOR
(
C
)
2
42 QYSSSF2608Z SCREW 2
43 LV31442-001A HEAT SINK 1
44 QYSBSF2608Z T.SCREW 7 FOR LV31446-001
45 QYSDSF2612E SCREW 4 FOR LV31447-001
46 LV31443-001A HEAT SINK BKT 1
47 QYSBSF2608Z T.SCREW 1 H.S.BKT+H.SINK
48 QYSBST3006Z T.SCREW 1 H.S.BKT+B.CHASSIS
49 QYSBST3006Z T.SCREW 2 B.CHASSIS+PWB
50 QYSBST3006Z T.SCREW 1 H.S.BKT+PWB
52 E47227-029 FOOT 2
