UX-G6/FS-G6
Parts list (AX-UXG6 General assembly)
Item
Parts number Parts name
Area
Q'ty
Description
Block No
.
M1MM
53 QYSBST3006Z T.SCREW 2 FOR FOOT
54 QYSBSG3010E T.SCREW 1 FOR HEAT SINK
55 LV41621-001A BARRIER
(
B
)
1 FOR HEAT SINK
58 LV10273-001A/S/ METAL COVER 1
59 QYSDSG3008N T.SCREW 2 M.COVER+B.CHASSIS
60 QYSDSG3008N T.SCREW 4 M.COVER+R.PANEL
61 LV20526-018A REAR PANEL 1 UP
LV20526-012A REAR PANEL 1 U,UB
62 QYSDSG3008N T.SCREW 1
63 E409257-001 GND TERMINAL 1
64 QYSDSG3008N T.SCREW 2 FOR SPK TERMINAL
65 QYSDSG3008N T.SCREW 1 FOR SUB WOOFER
66 QYSDSG3008N T.SCREW 1 FOR SYS.CONNECT
67 LV41755-001A CAUTION LABEL 1
68 QQT0273-004 POWER TRANSF 1 T001
69 QYSDSTL4008E SPECIAL SCREW 4 FOR TRANS
70 LV31816-002A BARRIER
(
A
)
1 FOR TRANS
71 QMPK090-205-JN POWER CORD 1 U
QMPN100-200-JD POWER CORD 1 UB
EMP7000-200 POWER CORD 1 UP
72 QZW0033-001 STRAIN RELIEF 1
73 QMF51E2-R50-J1 FUSE 1 F9801
74 QMF51E2-2R5-J1 FUSE 1 F9001
75 QUQB12-2018BJ FFC WIRE 1
76 QUQ810-1911AJ FFC WIRE 1
77 LV31447-001A HOLDER 1 FOR Q1011-Q1014
78 LV31446-001A IC BRACKET 1 FOR Q9201-
79 WJK0081-001A E-SI C WIRE C-B 1 UP
WJK0075-001A E-SI C WIRE C-B 1 U,UB
80 QJQ007-032001 SHI CR B-B WIRE 1
81 QJK018-070907 SIN CR C-B WIRE 1
82 QQR0216-001 NOISE FILTER 1
83 QYSBSG2608M T.SCREW 2 U,UB
84 QMF51E2-1R0-J1 FUSE 1 F9901
U,UB
