JVC FS-G6 Service Manual

3-5
UX-G6/FS-G6
Electrical parts list (System control & Main amplifier board) Block No. 01
Item Parts number Parts name AreaRemarks
CN701
Q
GF1016F3-19 CONNECTOR
CN702
Q
GF1016C1-19 CONNECTOR
CN704
Q
GF1201F3-20 FFC/FPC CONNE
CN711
Q
GA2001C1-07 7P PLUG ASSY
CN901
Q
JK024-041504 SIN CR C-B WIRE
CN903
Q
GA2501C3-04Z CONNECTOR
CN904
Q
GA3901C1-04 4P CONNECTOR
CN905
Q
GA7901C1-03 CONNECTOR
CN906
Q
GD2501C1-03Z SOCKET CN906
CN907
Q
GD2501C1-04Z SOCKET DOOR OPEN/CLOSE
CN908
Q
GF1201C3-20 FFC/FPC CONNE TO FRONT
(
CN704
)
CN909
Q
GA1502F1-19 19P CONNECTOR TO XT-UXG6
CN910
Q
GD2501C1-05Z SOCKET CN910
CN911
Q
GB2510J1-12 CONNECTOR
CN912
Q
GB2510K2-12 CONNECTOR
CN916
Q
GD2501C1-04Z SOCKET CN906
CN920
Q
GD2501C1-04Z SOCKET CN910
C1001
Q
FZ0202-104Z M CAPACITOR .10MF
C1002
Q
FZ0202-104Z M CAPACITOR .10MF
C1003
Q
FZ0202-104Z M CAPACITOR .10MF
C1004
Q
FZ0202-104Z M CAPACITOR .10MF
C1007
Q
TE1E28-476Z E CAPACITOR
C1008
Q
TE1E28-476Z E CAPACITOR
C1009
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C1010
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C1011
Q
CS11HJ-150 C CAPACITOR 15PF 5% 50V
C1012
Q
CS11HJ-150 C CAPACITOR 15PF 5% 50V
C1013
Q
CS11HJ-270 C CAPACITOR 27PF 5% 50V
C1014
Q
CS11HJ-270 C CAPACITOR 27PF 5% 50V
C1015
Q
CS11HJ-470 C CAPACITOR 47PF 5% 50V
C1016
Q
CS11HJ-470 C CAPACITOR 47PF 5% 50V
C1017
Q
CS11HJ-470 C CAPACITOR 47PF 5% 50V
C1018
Q
CS11HJ-470 C CAPACITOR 47PF 5% 50V
C1019
Q
FZ0202-104Z M CAPACITOR .10MF
C1020
Q
FZ0202-104Z M CAPACITOR .10MF
C1023
Q
ER61EM-226Z E CAPACITOR 22MF 20% 25V
C1024
Q
TE1E28-226Z E CAPACITOR
C1025
Q
FZ0202-104Z M CAPACITOR .10MF
C1026
Q
FZ0202-104Z M CAPACITOR .10MF
C1027
Q
FLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C1028
Q
FLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C1029
Q
ER61EM-106Z E CAPACITOR 10MF 20% 25V
C1030
Q
ETC1EM-476Z E CAPACITOR 47MF 20% 25V
C2010
Q
DGB1HK-102Y C CAPACITOR
C2101
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C7001
Q
ETC1HM-105Z-JB E CAPACITOR 1.0MF 20% 50V
C7002
Q
ETC1HM-105Z-JB E CAPACITOR 1.0MF 20% 50V
C7003
Q
DVB1EZ-223Y C CAPACITOR
C7004
Q
CBB1HK-223Y C CAPACITOR .022MF 10% 50V
C7005
Q
ETC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C7006
Q
ER61HM-106Z E CAPACITOR 10MF 20% 50V
C7101
Q
ETC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C7102
Q
DVB1EZ-223Y C CAPACITOR
C7103
Q
DVB1EZ-223Y C CAPACITOR
C7108
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C7110
Q
DXB1CM-222Y C.CAPA IM
C9101
Q
CF11HZ-103 C CAPACITOR .010MF +80:-20%
C9102
Q
ETM1EM-108 E CAPACITOR 1000MF 20% 25V
C9103
Q
ETC1AM-107Z-JB E CAPACITOR 100MF 20% 10V
C9104
Q
ETC1AM-107Z-JB E CAPACITOR 100MF 20% 10V
C9105
Q
DYB1CM-103Y C.CAPACITOR
C9106
Q
ETC1HM-227Z E CAPACITOR 220MF 20% 50V
C9107
Q
ETC1HM-107Z E CAPACITOR 100MF 20% 50V
C9108
Q
ETC1HM-226Z E CAPACITOR 22MF 20% 50V
C9109
Q
ETC1HM-226Z E CAPACITOR 22MF 20% 50V
C9110
Q
DYB1CM-103Y C.CAPACITOR
C9111
Q
ER61HM-475Z E CAPACITOR 4.7MF 20% 50V
C9112
Q
CZ9019-472 C CAPACITOR 4700PF
C9113
Q
FVF1HJ-104Z TF CAPACITOR .10MF 5% 50V
C9114
Q
FVF1HJ-104Z TF CAPACITOR .10MF 5% 50V
C9201
Q
TE1E28-476Z E CAPACITOR
C9202
Q
TE1C06-476Z E CAPACITOR
C9203
Q
DYB1CM-103Y C CAPACITOR
C9204
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C9205
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C9206
Q
TE1C28-476Z E CAPACITOR
C9207
Q
TE1C28-476Z E CAPACITOR
C9208
Q
FZ0202-103Z M CAPACITOR .010MF
C9209
Q
TE1C28-476Z E CAPACITOR
C9210
Q
TE1C28-476Z E CAPACITOR
C9211
Q
FZ0202-103Z M CAPACITOR .010MF
C9212
Q
DYB1CM-103Y C CAPACITOR
C9401
Q
ETC1CM-226Z-JB E CAPACITOR 22MF 20% 16V
C9402
Q
ER61CM-226Z E CAPACITOR 22MF 20% 16V
C9403
Q
DYB1CM-103Y C.CAPACITOR
C9404
Q
DYB1CM-103Y C.CAPACITOR
C9504
Q
ETC1HM-225Z-JB E CAPACITOR 2.2MF 20% 50V
C9505
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C9701
Q
CF11HZ-103 C CAPACITOR .010MF +80:-20%
C9705
Q
ETM1EM-688 E CAPACITOR 6800MF 20% 25V
C9706
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C9901
Q
TE1V27-338 E CAPACITOR
C9902
Q
TE1V27-338 E CAPACITOR
C9903
Q
CF11HZ-103 C CAPACITOR .010MF +80:-20%
DI701
Q
LF0067-001 FL TUBE
D1001 1SS133-T2 SI DIODE
D1002 1SS133-T2 SI DIODE
D1003 1SS133-T2 SI DIODE
D1004 1SS133-T2 SI DIODE
D1005 MTZJ18C-T2 Z.DIODE +18V
D1006 MTZJ18C-T2 Z.DIODE -18V
D1009 1SS133-T2 SI DIODE
D1010 1SS133-T2 SI DIODE
D1011 1SS133-T2 SI DIODE
D1012 1SS133-T2 SI DIODE
D2001 1SS133-T2 SI DIODE
D7001 SELU1E10CXM LED JOG2 BLUE
D7002 SELU1E10CXM LED JOG2 BLUE
D7003 SELU1E10CXM LED JOG1 BLUE
D7004 SELU1E10CXM LED JOG1 BLUE
D7007 SPR-39MVWF LED STBY/POWER LED
D7008 1SS133-T2 SI DIODE
D7009 1SS133-T2 SI DIODE
D7010 1SS133-T2 SI DIODE
D7011 MTZJ7.5A-T2 Z.DIODE FOR BLUE LED
D7012 MTZJ7.5A-T2 Z.DIODE FOR BLUE LED
D7101 1SS133-T2 SI DIODE
D7102 1SS133-T2 SI DIODE
D7105 1SS133-T2 SI DIODE
D7106 1SS133-T2 SI DIODE
D9101 1SR35-400A-T5 DIODE
D9102 MTZJ6.2C-T2 Z.DIODE
D9103 MTZJ7.5A-T2 Z.DIODE
D9106 1SR35-400A-T5 DIODE
D9107 1SR35-400A-T5 DIODE
D9108 1SR35-400A-T5 DIODE
Item Parts number Parts name AreaRemarks
