JVC FS-G6 Service Manual

3-6
UX-G6/FS-G6
Electrical parts list (System control & Main amplifier board) Block No. 01
Item Parts number Parts name AreaRemarks
D9109 MTZJ33C-T2 Z DIODE
D9110 MTZJ5.1C-T2 ZENER DIODE
D9112 1SS133-T2 SI DIODE
D9201 MTZJ3.3A-T2 ZENER DIODE
D9202 MTZJ8.2C-T2 ZENER DIODE
D9203 MTZJ11C-T2 ZENER DIODE
D9204 MTZJ13C-T2 ZENER DIODE
D9205 MTZJ13C-T2 ZENER DIODE
D9206 MTZJ13C-T2 ZENER DIODE
D9301 1SS133-T2 SI DIODE
D9302 1SS133-T2 SI DIODE
D9303 1SS133-T2 SI DIODE
D9401 MTZJ7.5A-T2 ZENER DIODE
D9402 MTZJ5.1C-T2 ZENER DIODE
D9504 MTZJ5.1A-T2 ZENER DIODE
D9505 1SS133-T2 SI DIODE
D9506 1SS133-T2 SI DIODE
D9507 1SS133-T2 SI DIODE
D9508 MTZJ5.1A-T2 ZENER DIODE
D9701 11E2-T5 DIODE
D9702 11E2-T5 DIODE
D9703 11E2-T5 DIODE
D9704 11E2-T5 DIODE
D9705 11E2-T5 DIODE
D9706 11E2-T5 DIODE
D9707 11E2-T5 DIODE
D9708 11E2-T5 DIODE
D9901 1N5401-TM DIODE
D9902 1N5401-TM DIODE
D9903 1N5401-TM DIODE
D9904 1N5401-TM DIODE
EP971
Q
NZ0136-001Z EARTH PLATE
EP972
Q
NZ0136-001Z EARTH PLATE
FH701 LV31441-001A FL HOLDER
FT911
Q
NG0020-001Z FUSE CLIP FOR F9001
FT912
Q
NG0020-001Z FUSE CLIP FOR F9001
FT981
Q
NG0020-001Z FUSE CLIP FOR F9801
FT982
Q
NG0020-001Z FUSE CLIP FOR F9801
FT991
Q
NG0020-001Z FUSE CLIP FOR F9901
FT992
Q
NG0020-001Z FUSE CLIP FOR F9901
FW901 WJK0082-001A E-SI C WIRE C-B
FW902
Q
UM027-08DGZ4 PARA RIBON WIRE
FW903
Q
UM029-09DGZ4 PARA RIBON WIRE
FW904
Q
UM024-12DGZ4 PARA RIBON WIRE
IC101 NJM5532D IC
IC701 UPD780023AGKA15 IC
IC901 LB1641 IC
JS701
Q
SW0739-001 R ENCODER JOG1
JS702
Q
SW0739-001 R ENCODER JOG2
(
VOL
)
J2001
Q
NB0082-001 SPK TERMINAL
J2002
Q
NN0017-001 PIN JACK BASS OUT
K7001
QQ
R0601-001Z F.BEADS I.M MI+5.6V
K7002
QQ
R0601-001Z F.BEADS I.M DGND
L1001
QQ
LZ005-R45 INDUCTOR
L1002
QQ
LZ005-R45 INDUCTOR
Q
1001 2SC2240/G/-T TRANSISTOR
Q
1002 2SC2240/G/-T TRANSISTOR
Q
1003 2SA970/G/-T TRANSISTOR
Q
1004 2SA970/G/-T TRANSISTOR
Q
1005 2SA970/G/-T TRANSISTOR
Q
1006 2SA970/G/-T TRANSISTOR
Q
1007 2SC2240/G/-T TRANSISTOR
Q
1008 2SC2240/G/-T TRANSISTOR
Q
1009 2SC2240/GL/-T TRANSISTOR +18V
Q
1010 2SA970/GL/-T TRANSISTOR -18V
Q
1011 2SK2382 F.E.T. U,UB
Q
1011 2SK2381 F.E.T. UP
Q
1012 2SK2381 F.E.T. UP
Q
1012 2SK2382 F.E.T. U,UB
Q
1013 2SJ334 F.E.T. U,UB
Q
1013 2SJ407 F.E.T. UP
Q
1014 2SJ407 F.E.T. UP
Q
1014 2SJ334 F.E.T. U,UB
Q
1015 2SD637/
Q
R/ TRANSISTOR
Q
1016 2SD637/
Q
R/ TRANSISTOR
Q
1017 2SA970/GL/-T TRANSISTOR
Q
1018 2SA970/GL/-T TRANSISTOR
Q
1019 KTC3199/GL/-T TRANSISTOR
Q
1020 2SA733/
Q
P/-T TRANSISTOR
Q
1021 KTC3199/GL/-T TRANSISTOR
Q
2001 2SC945/
Q
P/-T TRANSISTOR
Q
2101 2SC3576-JVC-T TRANSISTOR
Q
2102 2SC3576-JVC-T TRANSISTOR
Q
2103 KRA104M-T D.TRANSISTOR
Q
7001 KRC107M-T D.TRANSISTOR JOG2 BLUE
Q
7002 KRC107M-T D.TRANSISTOR JOG1 BLUE
Q
7005 KRC107M-T D.TRANSISTOR LED DIMER
Q
7006 KRC107M-T D.TRANSISTOR LED DIMER
Q
7101 2SC3576-JVC-T TRANSISTOR FL ON/OFF
Q
7102 2SC3576-JVC-T TRANSISTOR FL ON/OFF
Q
9101 2SD2394/EF/ TRANSISTOR
Q
9102 2SD400MP/EF/-T TRANSISTOR
Q
9103 KTC3199/GL/-T TRANSISTOR
Q
9104 KRA102M-T D.TRANSISTOR
Q
9105 KRC104M-T D.TRANSISTOR
Q
9201 2SD2394/EF/ TRANSISTOR
Q
9202 2SD2394/EF/ TRANSISTOR
Q
9203 KTC3199/GL/-T TRANSISTOR
Q
9204 KTC3199/GL/-T TRANSISTOR
Q
9205 KTC3199/GL/-T TRANSISTOR
Q
9206 2SD2394/EF/ TRANSISTOR
Q
9207 KTC3199/GL/-T TRANSISTOR
Q
9208 2SD2394/EF/ TRANSISTOR
Q
9209 2SC2240/GL/-T TRANSISTOR
Q
9210 2SB1565/EF/ TRANSISTOR
Q
9211 2SA970/GL/-T TRANSISTOR
Q
9213 2SD2394/EF/ TRANSISTOR
Q
9401 2SD400MP/EF/-T TRANSISTOR
Q
9504 KRC107M-T D.TRANSISTOR
Q
9505 KRC107M-T D.TRANSISTOR
Q
9506 KRC107M-T D.TRANSISTOR
RY201
Q
SK0115-001 RELAY
RY901
Q
SK0113-001 RELAY
R1001
Q
RE141J-912Y C RESISTOR 9.1K 5% 1/4W
R1002
Q
RE141J-912Y C RESISTOR 9.1K 5% 1/4W
R1003
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R1004
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R1005
Q
RZ0214-821Y C RESISTOR 820 1/2W
R1006
Q
RZ0214-821Y C RESISTOR 820 1/2W
R1007
Q
RZ0214-473Y C RESISTOR 47K 1/2W
R1008
Q
RZ0214-473Y C RESISTOR 47K 1/2W
R1009
Q
RJ146J-331X UNF C.RESISTOR 330 5% 1/4W
R1010
Q
RJ146J-331X UNF C.RESISTOR 330 5% 1/4W
R1011
Q
RZ0214-472Y C RESISTOR 4.7K 1/2W
R1012
Q
RZ0214-472Y C RESISTOR 4.7K 1/2W
R1013
Q
RZ0214-472Y C RESISTOR 4.7K 1/2W
Item Parts number Parts name AreaRemarks
U,UB
U,UB
