JVC FS-G6 Service Manual

3-17
UX-G6/FS-G6
Electrical parts list (CD servo & Main board) Block No. 03
Item Parts number Parts name AreaRemarks
CN431
Q
GD1501C1-19 F.WIRE SKT FOR SWIRE
(
TO AX
CN432
Q
GA1502F1-17 W TO B CONNE FROM XM
CN433
Q
GA1502F1-13 W TO B CONNE FROM DECK
CN434
Q
GB2510J1-06 CONNECTOR TO TUNER RELAY
CN435
Q
GB2510J1-13 CONNECTOR TO VOL PWB
CN436
Q
GB1214J1-18S CONNECTOR TO VOL PWB
CN437
Q
GB1214J1-18S CONNECTOR TO VOL PWB
CN438
Q
GA2001C1-05 5P PLUG ASSY TO CD TRAY
CN439
Q
GF1023F1-15 15PIN CONNECTOR FOR OPT-7
CN440
Q
GA2001C1-06 6P PLUG ASSY T0 CD MOTOR
CN441
Q
GA2001F1-02 2P CONNECTOR
CN443
Q
GB2510K2-06 CONNECTOR TO MICON
CN444
Q
GB2510K2-07 CONNECTOR TO CD CTL
C4101
Q
CBB1HK-561Y C CAPACITOR 560PF 10% 50V
C4102
Q
FN41HJ-682 M CAPACITOR 6800PF 5% 50V
C4103
Q
FN31HJ-473Z M CAPACITOR .047MF 5% 50V
C4104
Q
TE1C06-226Z E CAPACITOR
C4112
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C4124
Q
FLC1HJ-562Z M CAPACITOR 5600PF 5% 50V
C4201
Q
CBB1HK-561Y C CAPACITOR 560PF 10% 50V
C4202
Q
FN41HJ-682 M CAPACITOR 6800PF 5% 50V
C4203
Q
FN31HJ-473Z M CAPACITOR .047MF 5% 50V
C4204
Q
TE1C06-226Z E CAPACITOR
C4212
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C4224
Q
FLC1HJ-562Z M CAPACITOR 5600PF 5% 50V
C4301
Q
FVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C4302
Q
FVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C4311
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C4312
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C4313
Q
CBB1HK-561Y C CAPACITOR 560PF 10% 50V
C4321
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C4322
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C4331
Q
ETC1AM-476Z-JB E CAPACITOR 47MF 20% 10V
C4332
Q
ETC1AM-476Z E CAPACITOR 47MF 20% 10V
C4333
Q
CBB1HK-103Y C CAPACITOR .010MF 10% 50V
C4341
Q
ETC1AM-476Z-JB E CAPACITOR 47MF 20% 10V
C4342
Q
ETC1AM-476Z-JB E CAPACITOR 47MF 20% 10V
C4343
Q
CBB1HK-103Y C CAPACITOR .010MF 10% 50V
C4601
Q
DCB1HJ-120Y C CAPACITOR
C4602
Q
DCB1HJ-120Y C CAPACITOR
C4603
Q
CZ0205-155Z ML C CAPACITOR 1.5MF
C4604
Q
ETC0JM-477Z E CAPACITOR 470MF 20% 6.3V
C4605
Q
FVJ1HJ-154Z TF CAPACITOR .15MF 5% 50V
C4606
Q
DVB1EZ-223Y C CAPACITOR
C4607
Q
FN31HJ-223Z M CAPACITOR .022MF 5% 50V
C4608
Q
CZ0205-155Z ML C CAPACITOR 1.5MF
C4609
Q
ETC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C4610
Q
CBB1HK-471Y C CAPACITOR 470PF 10% 50V
C4611
Q
FVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C4612
Q
FVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C4613
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C4614
Q
CSB1HK-5R6Y C CAPACITOR 5.6PF 10% 50V
C4615
Q
CZ0205-155Z ML C CAPACITOR 1.5MF
C4616
Q
ETC0JM-477Z E CAPACITOR 470MF 20% 6.3V
C4617
Q
DGB1HK-102Y C CAPACITOR
C4619
Q
DGB1HK-102Y C CAPACITOR
C4620
Q
DGB1HK-102Y C CAPACITOR
C4621
Q
FVC1HJ-563Z M.M.CAPACITOR .056MF 5% 50V
C4622
Q
FVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C4623
Q
ETC1AM-107Z E CAPACITOR 100MF 20% 10V
C4624
Q
DYB1CM-103Y C CAPACITOR
C4625
Q
DXB1CM-472Y C CAPACITOR
C4626
Q
FN31HJ-273Z M CAPACITOR .027MF 5% 50V
C4627
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C4628
Q
ETC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C4629
Q
FVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C4630
Q
CF31HZ-223Z C CAPACITOR .022MF +80:-20%
C4631
Q
CZ0205-155Z ML C CAPACITOR 1.5MF
C4632
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C4633
Q
DVB1EZ-223Y C CAPACITOR
C4634
Q
DGB1HK-102Y C CAPACITOR
C4635
Q
DGB1HK-102Y C CAPACITOR
C4636
Q
CBB1HK-271Y C CAPACITOR 270PF 10% 50V
C4637
Q
CBB1HK-181Y C CAPACITOR 180PF 10% 50V
C4638
Q
DVB1EZ-223Y C CAPACITOR
C4639
Q
DVB1EZ-223Y C CAPACITOR
C4640
Q
DVB1EZ-223Y C CAPACITOR
C4641
Q
DVB1EZ-223Y C CAPACITOR
C4642
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C4643
Q
FLC1HJ-822Z M CAPACITOR 8200PF 5% 50V
C4644
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C4645
Q
CZ0205-155Z ML C CAPACITOR 1.5MF
C4646
Q
ETC1CM-477Z E CAPACITOR 470MF 20% 16V
C4647
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C4648
Q
FLC1HJ-562Z M CAPACITOR 5600PF 5% 50V
C4652
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C4663
Q
CZ0205-155Z ML C CAPACITOR 1.5MF
C4671
Q
CBB1HK-103Y C CAPACITOR .010MF 10% 50V
C4672
Q
ETC1AM-477Z E CAPACITOR 470MF 20% 10V
C4673
Q
ETC1AM-107Z E CAPACITOR 100MF 20% 10V
C4681
Q
FVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C4682
Q
CS11HJ-560 C CAPACITOR 56PF 5% 50V
C4683
Q
ETC1AM-107Z-JB E CAPACITOR 100MF 20% 10V
C4686
Q
CZ0205-155Z ML C CAPACITOR 1.5MF
C4691
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C4692
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C4693
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C5082
Q
DGB1HK-102Y C CAPACITOR
C5083
Q
CBB1HK-471Y C CAPACITOR 470PF 10% 50V
C5084
Q
CBB1HK-471Y C CAPACITOR 470PF 10% 50V
C5086
Q
ETC1AM-107Z-JB E CAPACITOR 100MF 20% 10V
C5087
Q
DGB1HK-102Y C CAPACITOR
C5088
Q
DGB1HK-102Y C CAPACITOR
C5091
Q
CBB1HK-331Y C CAPACITOR 330PF 10% 50V
C5092
Q
CBB1HK-331Y C CAPACITOR 330PF 10% 50V
D4331 MTZJ5.6C-T2 ZENER DIODE
D4341 MTZJ10A-T2 ZENER DIODE
D4601 1SS133-T2 SI DIODE
D4663 1SS133-T2 SI DIODE
D4664 1SS133-T2 SI DIODE
D4671 MTZJ10C-T2 Z.DIODE
D4674 MTZJ9.1B-T2 ZENER DIODE
D4681 MTZJ4.7B-T2 Z DIODE
D5081 MTZJ10C-T2 Z.DIODE
D5082 SELU1E10CXM LED BLUE
D5083 1SS133-T2 SI DIODE
D5084 1SS133-T2 SI DIODE
D5085 1SS133-T2 SI DIODE
EP451
Q
NZ0136-001Z EARTH PLATE
IC431 NJM5532D IC
IC432 TC9164AN IC
IC433 NJM4580D IC
IC434 NJM4580D IC
IC461 MN35511AL IC
IC462 AN8806SB IC
IC463 BA6897FP-W IC
Item Parts number Parts name AreaRemarks
