JVC FS-G6 Service Manual

3-18
UX-G6/FS-G6
Electrical parts list (CD servo & Main board) Block No. 03
Item Parts number Parts name AreaRemarks
IC464 TA8409S IC
IC502 GP1U271X RM RECIVER
IH461 VYH7237-001SC IC HOLDER
IH462 VYH7237-003SC IC HOLDER
IH463 VYH7237-003SC IC HOLDER
J5001
Q
NS0027-001 JACK
K4603
QQ
R0779-001Z INDUCTOR
K4604
QQ
R0779-001Z INDUCTOR
K4609
QQ
R0779-001Z INDUCTOR
K4610
QQ
R0779-001Z INDUCTOR
K4612
QQ
R0779-001Z INDUCTOR
K4613
QQ
R0779-001Z INDUCTOR
K4619
QQ
R0779-001Z INDUCTOR
K4661
QQ
R0779-001Z INDUCTOR
K4662
QQ
R0779-001Z INDUCTOR
K4664
QQ
R0601-001Z F.BEADS
K4671
QQ
R0601-001Z F.BEADS
K4672
QQ
R0601-001Z F.BEADS
K5082
QQ
R0779-001Z INDUCTOR
L4121
QQ
R0590-001 FILTER
L4221
QQ
R0590-001 FILTER
L4681
QQ
L25CK-221Z INDUCTOR
L5081
QQ
L231K-470Y INDUCTOR
L5082
QQ
L231K-470Y INDUCTOR
Q
4332 KRC107M-T D.TRANSISTOR
Q
4333 KRA107M-T D.TRANSISTOR
Q
4334 2SC2785/FE/-T TRANSISTOR
Q
4341 2SC2785/FE/-T TRANSISTOR
Q
4621 2SA952/LK/-T TRANSISTOR
Q
4661 KTA1267/YG/-T TRANSISTOR
Q
4665 KRC102M-T D.TRANSISTOR
Q
4671 2SD2394/EF/ TRANSISTOR
R4101
Q
RE141J-183Y C RESISTOR 18K 5% 1/4W
R4102
Q
RE141J-183Y C RESISTOR 18K 5% 1/4W
R4103
Q
RE141J-243Y C RESISTOR 24K 5% 1/4W
R4104
Q
RE141J-243Y C RESISTOR 24K 5% 1/4W
R4105
Q
RE141J-821Y C RESISTOR 820 5% 1/4W
R4106
Q
RE141J-682Y C RESISTOR 6.8K 5% 1/4W
R4107
Q
RE141J-752Y C RESISTOR 7.5K 5% 1/4W
R4108
Q
RE141J-202Y C RESISTOR 2.0K 5% 1/4W
R4109
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R4114
Q
RE141J-133Y C RESISTOR 13K 5% 1/4W
R4123
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R4124
Q
RE141J-123Y C RESISTOR 12K 5% 1/4W
R4125
Q
RE141J-473Y C RESISTOR 47K 5% 1/4W
R4126
Q
RE141J-472Y C RESISTOR 4.7K 5% 1/4W
R4127
Q
RE141J-122Y C RESISTOR 1.2K 5% 1/4W
R4128
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R4201
Q
RE141J-183Y C RESISTOR 18K 5% 1/4W
R4202
Q
RE141J-183Y C RESISTOR 18K 5% 1/4W
R4203
Q
RE141J-243Y C RESISTOR 24K 5% 1/4W
R4204
Q
RE141J-243Y C RESISTOR 24K 5% 1/4W
R4205
Q
RE141J-821Y C RESISTOR 820 5% 1/4W
R4206
Q
RE141J-682Y C RESISTOR 6.8K 5% 1/4W
R4207
Q
RE141J-752Y C RESISTOR 7.5K 5% 1/4W
R4208
Q
RE141J-202Y C RESISTOR 2.0K 5% 1/4W
R4209
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R4214
Q
RE141J-133Y C RESISTOR 13K 5% 1/4W
R4223
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R4224
Q
RE141J-123Y C RESISTOR 12K 5% 1/4W
R4225
Q
RE141J-473Y C RESISTOR 47K 5% 1/4W
R4226
Q
RE141J-472Y C RESISTOR 4.7K 5% 1/4W
R4227
Q
RE141J-122Y C RESISTOR 1.2K 5% 1/4W
R4228
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R4311
Q
RE141J-331Y C RESISTOR 330 5% 1/4W
R4331
Q
RE141J-152Y C RESISTOR 1.5K 5% 1/4W
R4332
Q
RZ9005-470X F RESISTOR 47 1/0W
R4334
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R4335
Q
RE141J-272Y C RESISTOR 2.7K 5% 1/4W
R4341
Q
RE141J-821Y C RESISTOR 820 5% 1/4W
R4342
Q
RZ9005-470X F RESISTOR 47 1/0W
R4601
Q
RE141J-271Y C RESISTOR 270 5% 1/4W
R4602
Q
RE141J-331Y C RESISTOR 330 5% 1/4W
R4603
Q
RE141J-124Y C RESISTOR 120K 5% 1/4W
R4604
Q
RE141J-105Y C RESISTOR 1.0M 5% 1/4W
R4605
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R4606
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R4607
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R4608
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R4610
Q
RE141J-471Y C RESISTOR 470 5% 1/4W
R4611
Q
RE141J-155Y C RESISTOR 1.5M 5% 1/4W
R4614
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R4615
Q
RE141J-683Y C RESISTOR 68K 5% 1/4W
R4616
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R4621
Q
RE141J-125Y C RESISTOR 1.2M 5% 1/4W
R4622
Q
RE141J-113Y C RESISTOR 11K 5% 1/4W
R4623
Q
RE141J-100Y C RESISTOR 10 5% 1/4W
R4624
Q
RE141J-121Y C RESISTOR 120 5% 1/4W
R4625
Q
RE141J-120Y C RESISTOR 12 5% 1/4W
R4626
Q
RE141J-274Y C RESISTOR 270K 5% 1/4W
R4627
Q
RE141J-154Y C RESISTOR 150K 5% 1/4W
R4628
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R4629
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R4630
Q
RE141J-474Y C RESISTOR 470K 5% 1/4W
R4631
Q
RE141J-273Y C RESISTOR 27K 5% 1/4W
R4632
Q
RE141J-910Y C RESISTOR 91 5% 1/4W
R4641
Q
RE141J-223Y C RESISTOR 22K 5% 1/4W
R4642
Q
RE141J-222Y C RESISTOR 2.2K 5% 1/4W
R4643
Q
RE141J-472Y C RESISTOR 4.7K 5% 1/4W
R4644
Q
RE141J-223Y C RESISTOR 22K 5% 1/4W
R4645
Q
RE141J-822Y C RESISTOR 8.2K 5% 1/4W
R4646
Q
RE141J-473Y C RESISTOR 47K 5% 1/4W
R4647
Q
RE141J-222Y C RESISTOR 2.2K 5% 1/4W
R4648
Q
RE141J-222Y C RESISTOR 2.2K 5% 1/4W
R4664
Q
RJ146J-2R2X UNF C.RESISTOR 2.2 5% 1/4W
R4665
Q
RE141J-561Y C RESISTOR 560 5% 1/4W
R4671
Q
RT01DJ-4R7X MF RESISTOR 4.7 5% 1/1W
R4672
Q
RT01DJ-4R7X MF RESISTOR 4.7 5% 1/1W
R4673
Q
RE141J-151Y C RESISTOR 150 5% 1/4W
R4674
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R4675
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R4676
Q
RE141J-151Y C RESISTOR 150 5% 1/4W
R4677
Q
RE141J-363Y C RESISTOR 36K 5% 1/4W
R4681
Q
RE141J-471Y C RESISTOR 470 5% 1/4W
R5081
Q
RE141J-101Y C RESISTOR 100 5% 1/4W
R5082
Q
RE141J-101Y C RESISTOR 100 5% 1/4W
R5083
Q
RE141J-332Y C RESISTOR 3.3K 5% 1/4W
R5084
Q
RE141J-472Y C RESISTOR 4.7K 5% 1/4W
R5085
Q
RE141J-223Y C RESISTOR 22K 5% 1/4W
R5088
Q
RE141J-221Y C RESISTOR 220 5% 1/4W
S5001
Q
SW0674-001Z TACT SWITCH
S5002
Q
SW0674-001Z TACT SWITCH
S5003
Q
SW0674-001Z TACT SWITCH
W 451 WJP0012-001A E-SHI C WIRE C-
W 511 WJK0065-001A E-SI C WIRE C-B TO MICON/VOL
Item Parts number Parts name AreaRemarks
X4601
Q
AX0413-001Z CRYSTAL
<<CAUTION>>
Please note that "IC461" uses IC different
depending on the kind of the board.
For board No.LVB10107-001A
IC461 MN35511
For board No.LVB10107-001B/001C
IC461 MN35511AL
