JVC FS-X3 Service Manual

3-4
General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 LV10701-008A TOP CASE X1C,X1J
1 LV10701-007A TOP CASE X3C,X3J
2 LV33785-001A BUTTON BASE(A)
3 LV30225-0L4A SPECER (x4)
4 LV33774-001A FUNCTION IND.
5 LV33786-003A BUTTON BASE(B) X1C,X1J
5 LV33786-002A BUTTON BASE(B) X3C,X3J
6 LV33779-003A PUSH BUTTON(A) X1C,X1J
6 LV33779-002A PUSH BUTTON(A) X3C,X3J
7 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm(x5)
8 LV30225-0L3A SPECER
9 LV43408-001A BARRIER(D)
10 LV41659-001A INSULATOR (x2)
11 LV41659-002A INSULATOR
12 LV43342-001A ASSIST SP
13 LV21332-002A PICK UP COVER
14 LV21333-002A CD MECHA HOLDER
15 LV43245-001A SPECIAL SCREW (x3)
16 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm(x3)
17 LV43306-001A CD BURRIER
18 VYSH101-009 SPECER
19 LV43589-001A SHEET(A)
20 LV21335-001A FRONT HOLDER
21 VYSH101-009 SPECER
22 LV33775-003A POWER KNOB ASSY X1C,X1J
22 LV33775-002A POWER KNOB ASSY X3C,X3J
23 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm(x3)
24 QYSBSF2610Z SCREW 2.6mm x 10mm(x2)
25 LV10703-005A CD DOOR X1C,X1J
25 LV10703-004A CD DOOR X3C,X3J
26 QYSDSF2005N SCREW 2mm x 5mm
27 LV43618-001A CD CAUTION
28 LV10704-001A CD DOOR COVER
29 QYSDSF2005N SCREW 2mm x 5mm(x5)
30 LV33788-001A GEAR HOLDER
31 VKS5548-001 MOTOR PULLEY
32 QAR0164-001 MOTOR
33 QYSPSPU1722Z SCREW M1.7 x 2.2mm(x2)
34 LV43222-001A BELT
35 LV43152-001A PULLEY WORM
36 LV43155-001A WORM WHEEL
37 LV43151-001A GEAR(A)
38 LV43206-001A GEAR(B)
39 LV43153-001A WHEEL STOPPER
40 QYSDSF2006Z SCREW 2mm x 6mm(x2)
41 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm
42 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm(x3)
43 LV43386-001A GEAR BKT
44 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm(x2)
45 LV30225-0K9A SPECER
46 LV10705-002A BOTTOM CHASSIS
47 QYSBSG3006E TAPPING SCREW 3mm x 6mm(x3)
48 LV43446-001A PWB BKT (x2)
49 QYSBSG3006E TAPPING SCREW 3mm x 6mm(x2)
50 QYSBSG3006E TAPPING SCREW 3mm x 6mm(x2)
51 QYSBSG3006E TAPPING SCREW 3mm x 6mm
52 LV30225-0H8A SPECER
53 LV34250-001A BARRIER(E)
54 LV34251-001A BARRIER(F)
55 LV10796-001A CENTER CHASSIS
56 LV30225-0M2A SPECER
57 QYSBSF3008Z SCREW 3mm x 8mm(x3)
58 QAR0272-001 FAN MOTOR
59 LV34051-002A FAN BRACKET
60 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm
61 QYSDST2616M SCREW M2.6 x 16mm
62 QYSBSG3016Z TAPPING SCREW M3 x 16mm(x2)
63 QYSBSF3010Z SCREW 3mm x 10mm(x2)
64 QYSBSG3006E TAPPING SCREW 3mm x 6mm(x2)
65 LV43407-005A RUBBER SHEET
66 LV43400-002A SHIELD TIGHT
67 LV43400-003A SHIELD TIGHT
68 LV43452-002A HEAT SINK
69 LV43453-002A HEAT SINK BKT
70 LV33790-001A SHIELD(B)
71 LV33791-002A SHIELD(C)
72 LV43400-001A SHIELD TIGHT
73 QYSDSG2606Z SCREW M2.6 x 6mm(x2)
74 QYSDSG2606Z SCREW M2.6 x 6mm
75 QYSBST2604E TAPPING SCREW 2.6mm x 4mm(x4)
76 QYSBSG3006E TAPPING SCREW 3mm x 6mm(x3)
77 QYSBSF3010Z SCREW 3mm x 10mm(x2)
78 LV30225-0L1A SPECER
79 LV30225-074A SPECER
80 LV30225-0L1A SPECER
81 QYSBSF3010Z SCREW 3mm x 10mm(x2)
82 QYSBSG3006E TAPPING SCREW 3mm x 6mm(x2)
 83 QMPD380-200-JN POWER CORD(US/CA) 2m BLACK
 84 QZW0033-001 STRAIN RELIEF
85 LV30225-0L7A SPECER
86 LV30225-0L1A SPECER
87 LV10702-002A BOTTOM CASE(A)
88 LV21337-001A SIDE LENS(L)
89 LV21338-001A SIDE LENS(R)
90 LV30225-0M6A SPECER (x2)
91 LV30225-0M7A SPECER (x2)
92 LV30225-0M8A SPECER (x2)
93 QYSDSG3006N TAPPING SCREW M3 x 6mm(x5)
94 LV21334-003A BOTTOM CASE(B)
95 LV30225-0M8A SPECER (x2)
96 LV21336-001A FRONT LENS
97 LV43200-001A FL SCREEN
98 QYSBSF3014M SCREW 3mm x 14mm(x3)
99 LV33769-004A VOL KNOB ASSY X1C,X1J
99 LV33769-005A VOL KNOB ASSY X3C,X3J
100 LV33773-003A FUNCTION KNOB
101 LV33784-002A CONTROL BUTTON
102 LV33772-001A VOLUME RING
103 LV43433-001A VOL.SHEET
104 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm
105 LV33777-006A CYLINDER COVER X1C,X1J
105 LV33777-005A CYLINDER COVER X3C,X3J
106 LV43590-001A SHEET(B)
107 LV10706-009A REAR COVER
108 LV34189-001A COVER
109 LV34050-002A FAN COVER
110 QYSDST2616M SCREW M2.6 x 16mm(x2)
111 QYSDSG3010N TAPPING SCREW 3mm x 10mm(x2)
112 QYSDSG3010N TAPPING SCREW 3mm x 10mm(x5)
113 QYSDSG3010N TAPPING SCREW 3mm x 10mm(x2)
114 QYSDSG3010N TAPPING SCREW 3mm x 10mm(x6)
115 LV34243-003A RATING LABEL
X1C,X1J
115 LV34242-003A RATING LABEL X3C,X3J
116 LV40240-003A FOOT (x4)
117 LV33794-001A EARTH PLATE(A)
118 LV33865-001A EARTH PLATE(B)
119 VND5008-001 FCC LABEL(4)
120 VND4118-003 CAUTION LABEL
121 LV43513-001A CAUTION LABEL
 122 QMF51U1-2R5-J8 FUSE
F 9101 2.5A
AC125V
123 QYSBSG3010E TAPPING SCREW 3mm x 10mm
124 QYSBST3006E TAPPING SCREW 3mm x 6mm
125 LV33783-001A HOLDER
126 VYSH101-009 SPECER
127 QYSBST3006E TAPPING SCREW 3mm x 6mm(x3)
128 QAU0307-002 TUNER
129 QUQ110-1313BF FFC
130 QUQ110-0715AF FFC
131 QUQ410-0908CF FFC
132 QUQ710-1924AF FFC
133 QUQ412-1112DJ FFC WIRE
134 WJM0017-001A E-SI C WIRE C-F
135 QJJ055-261101 SIN CR C-C WIRE
 Symbol No. Part No. Part Name Description Local
