JVC FS-X3 Service Manual

3-15
CD servo board
Block No. [0][3][0][0]
CN871 QGF1205F1-11 CONNECTOR FFC/FPC (1-11)
CN941 QGB2510K2-12 CONNECTOR B-B (1-12)
CN961 QGB1214J1-06S CONNECTOR B-B (1-6)
CN981 QGB2510J1-04 CONNECTOR B-B (1-4)
 CP971 ICP-S1.2-X IC PROTECTOR 1.2A
EP731 QNZ0136-001Z EARTH PLATE
FW701 QUM036-10Z3Z3 PARA RIBON WIRE
HS941 LV43250-001A HEAT SINK
HS971 LV43250-001A HEAT SINK
HS991 LV43250-002A HEAT SINK
K3001 NQR0389-003X FERRITE BEADS
K3002 NQR0389-003X FERRITE BEADS
K3003 NQR0389-003X FERRITE BEADS
K3004 NQR0389-003X FERRITE BEADS
K3005 NQR0389-003X FERRITE BEADS
LS711 QSW0992-001 ROTARY ENCODER
LS712 QSW0993-001 ROTARY ENCODER
S7101 QSW0683-001Z PUSH SW
S7102 QSW0683-001Z PUSH SW
S7103 QSW0683-001Z PUSH SW
S7104 QSW0683-001Z PUSH SW
S7105 QSW0683-001Z PUSH SW
S7106 QSW0683-001Z PUSH SW
S7301 QSW0683-001Z PUSH SW
WR471 WJK0154-001A WIRE
WR803 QJK005-061601 WIRE
X3001 QAX0734-001 C RESONATOR 400.00kHz
X3002 QAX0735-001 C RESONATOR 420.00kHz
X8001 QAX0401-001 CRYSTAL 32.768KHz
X8301 QAX0416-001Z C RESONATOR 8.000MHz
 Symbol No. Part No. Part Name Description Local
IC251 UPD780024AGKB92 IC
IC291 XC62HR3502P-X IC Regulator
IC601 AN22000A-W IC RF & SERVO AMP
IC651 MN662790RSC IC
IC801 LA6541-X IC
Focus & Spindle &
Feed & Tracking
BTL driver
Q631 2SA1037AK/RS/-X TRANSISTOR
Q651 DTC114EUA-X DIGI TRANSISTOR
Q652 DTC114EUA-X DIGI TRANSISTOR
Q673 UN2111-X TRANSISTOR
Q801 UN2215-X TRANSISTOR
D292 MA112-X DIODE
D603 1SS355-X SI DIODE
C254 QERF1AM-476Z E CAPACITOR 47uF 10V M
C255 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C271 NDC31HJ-101X C CAPACITOR 100pF 50V J
C272 NDC31HJ-101X C CAPACITOR 100pF 50V J
C273 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C291 NCB21CK-105X C CAPACITOR 1uF 16V K
C292 NCB21CK-105X C CAPACITOR 1uF 16V K
C601 NCB31HK-102X C CAPACITOR 1000pF 50V K
C602 NCB31HK-102X C CAPACITOR 1000pF 50V K
C603 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C604 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C605 NCB31HK-271X C CAPACITOR 270pF 50V K
C606 NDC31HJ-820X C CAPACITOR 82pF 50V J
C610 NCB31CK-563X C CAPACITOR 0.056uF 16V K
C611 NCB21CK-104X C CAPACITOR 0.1uF 16V K
C612 QEKC1HM-104Z E CAPACITOR 0.1uF 50V M
C614 NCB31CK-393X C CAPACITOR 0.039uF 16V K
C615 NCB31HK-272X C CAPACITOR 2700pF 50V K
C616 NCB31HK-182X C CAPACITOR 1800pF 50V K
C617 NCB31HK-331X C CAPACITOR 330pF 50V K
C621 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local
C622 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C623 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C624 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C631 QEKC1CM-106Z E CAPACITOR 10uF 16V M
C632 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C633 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C651 NDC31HJ-1R0X C CAPACITOR 1pF 50V J
C652 NDC31HJ-1R0X C CAPACITOR 1pF 50V J
C653 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C655 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C656 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C657 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C658 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C661 NCB31HK-471X C CAPACITOR 470pF 50V K
C663 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C664 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C665 NCB21CK-154X C CAPACITOR 0.15uF 16V K
C667 NCB21CK-474X C CAPACITOR 0.47uF 16V K
C668 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C673 QER60JM-107Z E CAPACITOR 100uF 6.3V M
C676 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C677 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C678 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C679 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C680 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C681 NDC31HJ-4R0X C CAPACITOR 4pF 50V J
C682 NDC31HJ-220X C CAPACITOR 22pF 50V J
C683 NDC31HJ-390X C CAPACITOR 39pF 50V J
C801 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C802 NCB31HK-102X C CAPACITOR 1000pF 50V K
C811 NCB31HK-391X C CAPACITOR 390pF 50V K
C812 NCB31HK-391X C CAPACITOR 390pF 50V K
C813 NCB31HK-391X C CAPACITOR 390pF 50V K
C814 NCB31HK-391X C CAPACITOR 390pF 50V K
C815 NCB21AK-105X C CAPACITOR 1uF 10V K
C816 NCB20JK-155X C CAPACITOR 1.5uF 6.3V K
C817 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C818 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C821 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C822 QERF1AM-227Z E CAPACITOR 220uF 10V M
C861 NCB31HK-102X C CAPACITOR 1000pF 50V K
C862 NCB31HK-102X C CAPACITOR 1000pF 50V K
C863 NCB31HK-272X C CAPACITOR 2700pF 50V K
C864 NCB31HK-272X C CAPACITOR 2700pF 50V K
R251 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R252 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R253 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R254 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R255 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R256 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R257 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R258 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R259 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R260 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R261 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R262 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R263 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R271 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R272 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R273 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R274 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R275 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R281 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R282 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R283 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R284 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R285 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R291 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R292 NRSA63J-1R0X MG RESISTOR 1 Ω 1/16W J
R293 NRSA63J-1R0X MG RESISTOR 1
Ω 1/16W J
R601 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R602 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R603 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R604 NRSA63J-224X MG RESISTOR 220k
Ω 1/16W J
R607 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R608 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R609 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
