JVC FS-X3 Service Manual

3-16
R611 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R613 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R617 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R631 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R632 NRSA63J-3R9X MG RESISTOR 3.9 Ω 1/16W J
R634 NRSA63J-3R9X MG RESISTOR 3.9
Ω 1/16W J
R635 NRSA63J-100X MG RESISTOR 10
Ω 1/16W J
R636 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R651 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R652 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R653 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R654 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R659 NRSA63J-203X MG RESISTOR 20k Ω 1/16W J
R661 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R662 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R663 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R664 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R665 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R666 NRSA02J-101X MG RESISTOR 100 Ω 1/10W J
R667 NRSA63J-4R7X MG RESISTOR 4.7 Ω 1/16W J
R668 NRSA63J-155X MG RESISTOR 1.5M
Ω 1/16W J
R669 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R671 NRSA63J-684X MG RESISTOR 680k Ω 1/16W J
R673 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R675 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R677 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R678 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R679 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R682 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R683 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R685 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R801 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R802 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R803 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R804 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R805 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R806 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R807 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R808 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R809 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R811 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R812 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R813 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R861 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R862 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R863 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R864 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
CN601 QGF1037F1-15W CONNECTOR FFC/FPC (1-15)
CN605 QGF1016F2-04W CONNECTOR FFC/FPC (1-4)
CN606 QGF1016F2-08W CONNECTOR FFC/FPC (1-8)
CN651 QGF1016F3-19 CONNECTOR FFC/FPC (1-19)
K655 NQR0007-002X FERRITE BEADS
K656 NQR0251-004X FERRITE BEADS
K657 NQR0251-004X FERRITE BEADS
K658 NQR0251-004X FERRITE BEADS
SW101 QSW0927-001 SWITCH
X251 QAX0664-001Z C RESONATOR
X651 NAX0476-001X CRYSTAL 33.8688MHz
 Symbol No. Part No. Part Name Description Local
