- 19 -
OSD Menu (cont.)
PIP / PBP SETTING
Displays the sub picture additionally on the main picture.
PIP(Picture in Picture)
PBP(Picture by Picture)
1. Press Up/Down buttons to select an icon
2. Press MENU button to enter
3. Press Up/Down buttons to adjust value
4. Press MENU button to return
5. Return to MAIN MENU by EXIT
PIP/PBP : Select the style of sub picture.(OFF/PI P/PBP)
SOURCE : Select the sub picture input source.
The combination of PIP and PBP is
1. Main screen is one of (RGB, DVI, HDMI, SDI) and PIP or PBP screen is
one of (VIDEO, S-VIDEO).
2. Main screen is one of (VIDEO, S-VIDEO) and PIP or PBP screen is one
of (RGB, DVI, HDMI, SDI).
LOCATION : Select the “PIP LOCATION” value 0 - 3.
RATIO : Select the "PIP size” value 0 - 2.
EXIT : Press MENU button to return to the main menu.
(To fix, must finish by EXIT menu.)
