How to use External Control (RS-232C) (cont.)
<Basic command list>
No.
Commands
Functions
Data
1*
! * * B C N 1 Cr
Starts communication(connection)
No data
2*
! * * B C N 0 Cr
Terminates communication (termination)
No data
3
! 00 B I D S E T x x Cr
Assigns the control ID
01-99
4
! * * B I D R E T Cr
Initializes the control ID
No data
5
! * * B I D D S P x x Cr
Displays/hides the ID
00: Hide, 01: Display
6
! * * B I D C H K x x Cr
Flashes/hides the selected ID No. of the monitor
00: Hide, 01: Flash
7
! * * B M E N U Cr
Displays the MAIN MENU/Quits the menu operation
No data
8
! * * B U P Cr
Moves the cursor upward (▲)
No data
9
! * * B D O W N Cr
Moves the cursor downward (▼)
No data
10
! * * B A D J R Cr
Makes setting/adjustment (►)
No data
11
! * * B A D J L Cr
Makes setting/adjustment (◄)
No data
12
! * * B S E T U P Cr
Displays the SET-UP MENU
No data
13*
! * * B P W 1 Cr
Turns on the monitor
No data
14
! * * B P W 0 Cr
Turns off the monitor
No data
15
! * * B I N A Cr
Selects Input VIDEO
No data
16
! * * B I N B Cr
Selects Input RGB
No data
17
! * * B I N C Cr
Selects Input DVI
No data
18
! * * B I N D Cr
Selects Input S-VIDEO
No data
19
! * * B I N E Cr
Selects Input HDMI
No data
20
! * * B I N F Cr
Selects Input SDI
No data
21
! * * B D I S P Cr
Displays the status
No data
22
! * * B V P L S Cr
Turns the volume up
No data
23
! * * B V M N S Cr
Turns the volume down
No data
24
! * * B V O L x x x Cr
Adjusts the volume
00-100
25
! * * B A M U T E x x Cr
Turns muting on/off
00: Off, 01: On
26
! * * B A S P T Cr
Changes the aspect ratio
No data
27
! * * B P I C M O D x x Cr
Selects the picture mode
00: ----------
01: -----------
02: USER
03: CCTV1
04: CCTV2
05: STUDIO
28
! * * B P I P P P B P x x Cr
Selects the sub picture display
00: Off
01: PIP
02: PBP
• These commands can be used while the monitor is on standby.
• "* *"substitutes the ID number of the monitor. The initial setting is "00". When 2 or more
monitors are connected and controled, the commands for the ID "00" controls all the
monitors.
• Enter the appropriate data to “x”, “xx” or “xxx.”
• “Cr” is 0Dh.
