JVC GM-552 User Manual

- 27 -
Specifications(cont.)
Signal Characteristics
VIDEO
:
1.0 V(p-p), automatic switching from 75 Ω unbalanced
termination to Hi-Z with loop-through operation.
S-VIDEO
Y
:
1.0 V(p-p) 75 Ω unbalanced termination.
C
:
Burst level
NTSC 0.286V(p-p) 75 Ω unbalanced termination.
PAL/SECAM 0.3 V(p-p) 75 Ω unbalanced termination.
RGB
R,G, B
:
0.7 V(p-p) 75 Ω unbalanced termination.
SYNC
:
TTL (positive/negative)
DVI-D
:
DVI-D signal
HDMI
:
HDMI signal
SDI(GM-552D
Only)
:
(3G-SDI) SMPTE424M / SMPTE425M LEVEL A-1
(HD-SDI) BTA S004C / SMPTE292M
(SD-SDI) ITU-R BT.656 / SMPTE259M
(EMBEDDED AUDIO) SMPTE299M / SMPTE272M
Analog AUDIO
:
500 mV(rms).
RS232C
:
"How to use the serial communication" on page 24.
DC OUT
:
DC +12 V output Max. 350 mA
• For easy understanding, pictures and illustrations are shown by being
emphasized, omitted or composed, and may be slightly different from
actual products.
• Design and specifications are subject to change without notice.
• All company names and product names mentioned herein are used for
identification purposes only, and may be the trademarks or registered
trademarks of their respective companies.
• HDMI, the HDMI Logo, and High - Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.
