JVC GR-AXM10 User Manual

EN 53
GENERAL
Format : VHS NTSC standard
Power source : DC 6V
Power consumption
LCD monitor off,
viewfinder on : GR-AXM20 : 6.5 W
GR-AXM10 : 6.3 W
LCD monitor on,
viewfinder off : 6.7 W
Light : 3 W
(GR-AXM20 only)
Signal system : NTSC-type
Video recording system
Luminance : FM recording
Color : Converted sub-carrier
direct recording
Conforms to VHS
standard
Cassette :
cassette
Tape speed
SP : 33.35 mm/sec.
(1-5/16 ips)
EP : 11.12 mm/sec. (7/16 ips)
Recording time (max.)
SP : 40 minutes
EP : 120 minutes
(with TC-40 cassette)
Operating temperature : 0°C to +40°C
(32°F to 104°F)
Operating humidity : 35% to 80%
Storage temperature : –20°C to +50°C
(–4°F to 122°F)
Weight
GR-AXM20 : Approx. 1010 g (2.3 lbs)
GR-AXM10 : Approx. 1030 g (2.3 lbs)
Dimensions
(Including viewfinder)
GR-AXM20 : 118 (W) x 115 (H) x
218 (D) mm (4-11/16” x
4-9/16” x 8-5/8”)
GR-AXM10 : 118 (W) x 115 (H) x
231 (D) mm (4-11/16” x
8-5/8” x 9-1/8”)
CAMERA
Pick up : 1/4” format CCD
Lens : F1.6, f = 3.8 to 68.4 mm,
18:1 power zoom lens
with auto iris and macro
control, filter diameter
46 mm
Viewfinder : Electronic viewfinder with
•0.55” color LCD
(GR-AXM20)
•0.5” black/white CRT
(GR-AXM10)
White balance
adjustment : Auto/Manual adjustment
LCD MONITOR
Size : 3" diagonally measured
LCD system : LCD/TFT active matrix
system
SPECIFICATIONS
VIDEO
Output : 1 Vp-p, 75 ohms,
unbalanced (via VIDEO
out connector)
AUDIO
Output : –8 dBs, 1 k-ohm
(via AUDIO out
connector)
Speaker : 20 mm round x 1,
monaural
AC POWER ADAPTER/BATTERY CHARGER
(AA-V11U)
Power requirement
U.S.A. and Canada : AC 120 V`, 60 HZ
Other countries : AC 110 V to 240 V`,
50/60 Hz
Power consumption : 23 W
Output
Charge : DC 8.5 V
, 1.3 A
VTR : DC 6.3 V
, 1.8 A
Charging system : Constant current, peak
detection, timer
controlled
Dimensions : 150 (W) x 42 (H) x
68 (D) mm (5-15/16” x
1-11/16” x 2-11/16”)
Weight : Approx. 320 g (0.71 lbs)
CASSETTE ADAPTER (C-P7U)
Dimensions : 188 (W) x 25 (H) x
104 (D) mm (7-7/16” x 1”
x 4-1/8”)
Weight : Approx. 240 g (0.53 lbs)
Accessory : “AA (R6)”-size battery x 1
Provided Accessories ...................... Z pg. 6
Optional Accessories
•Battery Packs BN-V12U, BN-V22U, BN-V25U
•Car Battery Charger BH-V3U
•Battery Charger BH-VC10U
•Car Battery Cord AP-V7U
•RF Unit RF-V5U
•Compact VHS-C Cassettes TC-40/30/20
•Active Carrying Bag CB-V7U
•Wireless Remote Control Unit RM-V700U
The RM-V700U cannot be used to operate the
GR-AXM10.
The GR-AXM10 can use the RM-V700U only for
R.A. Edit with a non-JVC VCR.
Some acccessories are not available in some areas.
Please consult your nearest JVC dealer for details on
accessories and their availability.
Specifications shown are for SP mode unless
otherwise indicated. E. & O. E. Design and
specifications subject to change without notice.

JVC GR-AXM10 Specifications
