EN 47
Controls
1 Power Zoom Button ........................... Z pg. 20
2 Multi-Function Control
•EFFECT Button .................................
Z pg. 26
•WIDE Button ................................... Z pg. 26
•TITLE Button ....................................
Z pg. 27
•SUPER LOLUX Button ......................
Z pg. 27
3 Select Dial ......................................... Z pg. 24
4 Recording Mode [SP/EP] Button.......... Z pg. 12
5 DATE/TIME Button ............................. Z pg. 22
COUNTER R/M Button .......................
Z pg. 38
6 5SEC. REC [5-sec recording] Button .... Z pg. 21
7 REW Button ....................................... Z pg. 36
RETAKE R [Quick Review] Button .......
Z pg. 21
8 PLAY/PAUSE Button ........................... Z pg. 36
9 FF Button ........................................... Z pg. 36
RETAKE F Button ................................ Z pg. 21
0 STOP Button ...................................... Z pg. 36
! EJECT Switch ...................................... Z pg. 13
@ PUSH Button ..................................... Z pg. 13
# LIGHT OFF/AUTO/ON Switch ........... Z pg. 23
$ BATT. [Battery] RELEASE Switch ......... Z pg. 8
% Diopter Adjustment............................ Z pg. 14
^ Function Navigator Dial
[MENU Jog Dial]................................ Z pg. 11
& Recording Start/Stop Button ................ Z pg. 16
* Power Switch .................................Z pg.16, 36
( LENS COVER Switch ......................... Z pg. 16
) BRIGHT Dial ..................................... Z pg. 37
q VOLUME Dial ................................... Z pg. 37
Connectors
w DC IN Jack......................................... Z pg. 9
The jacks e to y are located beneath the jack
cover.
e J terminal [JLIP (Joint Level Interface Protocol)
Connector.]
•It is used to connect the camcorder to a device
such as a personal computer.
For further detail consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with
a J terminal.
r VIDEO OUT Connector ......................Z pg. 40
t RF DC OUT Connector .......................Z pg. 40
y AUDIO OUT Connector ..................... Z pg. 40
Indicators
u Power Indicator ................................. Z pg. 16
i Tally Lamp ......................................... Z pg. 16
Other Parts
o Video Light ........................................ Z pg. 23
p Microphone
Q Camera sensor
Be careful not to cover this area; built-in
here is the sensor necessary for shooting.
W Clock Battery Compartment ................ Z pg. 10
E Battery Pack Mount ........................... Z pg. 8
R Shoulder Strap Eyelets ........................ Z pg. 15
T Electronic Viewfinder......................... Z pg. 14
Y Grip Strap .......................................... Z pg. 14
U Speaker .............................................. Z pg. 37
I LCD monitor ..................................Z pg.18, 36
O Tripod Mounting Socket ......................Z pg. 15
To Next Page
