JVC GR-AXM225U Service Manual

5-3
126 QYSLSF2055D SPECIAL SCREW
127 QYSLSF2055D SPECIAL SCREW,X2
128 QYSLSF2090D SCREW
129 QYSLSF2055D SPECIAL SCREW,X2
130 QYSLSF2055D SPECIAL SCREW,X2
131 QYSLSF2055D SPECIAL SCREW
132 QYSLSP2030D SCREW,X2
133 QYSLSF2090D SCREW
134 QYSLSF2055D SPECIAL SCREW,X2
135 QYSLSF2055D SPECIAL SCREW,X3
136 QYSLSF2055D SPECIAL SCREW
! 137 LY20372-004A FRAME ASSY
137A LY30903-001A BASE
137B LY41090-001B HOOK
137C QYSLSF2060D SCREW,X2
137D QYSLSF2060Z SCREW,X2
137E LY30016-0H2A SPACER-A
137F YQ43810 CONTACT(LIGHT),X2
137G WJM0118-001A E-SI C WIRE C-F
137H LY41082-001A CUSHION(OP),X2
138 YQ44457-3 SCREW,X2
139 LY30904-001A BKT(MECHA)
140 QYSPSTU1725M SCREW
142 LY30018-050A SPECIAL SCREW,X2
143 LY41173-001A SPECIAL SCREW,X2
144 QYSLSF1750D SCREW
145 QYSLSF2055D SPECIAL SCREW,X2
146 LY41083-001B KNOB(LIGHT)
147 WJT0024-001A E-CARD WIRE,OP-MAIN CN15
148 LY30889-001B CAP(LITHIUM)
150 LY30514-001F FRONT FRAME ASSY
150A YQ44144-1-1 TAPE GUIDE
151 SPSH1725M SCREW,X2
152 YQ31752H-31 CASSETTE HOUSING ASSY
152A LY30175-001C CASSETTE COVER INSIDEASSY
153 YQ44457-3 SCREW,X4
154 QYSLSP2025D SCREW,X2
155 QYSLSP2030D SCREW,X4
– OPTICAL BLOCK SECTION –
251 LY30948-003A OP BLOCK ASSY
251A PTY30948-002 FOCUS MOTOR
251B PTY30948-301 ZOOM MOTOR
251C PTY30151-016 SCREW,X9
251D PTY30948-006 IRIS MOTOR UNIT,INCL.FPC
252 LYH40047-001A CCD BASE ASSY
253 QYSPSGU2080Z SCREW,X2
254 LY31441-001A SPACER RUBBER
255 LY41755-001A OPTICAL LPF
256 LY20346-001A CCD SPACER
257 LY30018-072A SPECIAL SCREW
✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽
FINAL ASSEMBLY <M2>
! 101 LY10122-047A LOWER CASE ASSY
101A LY30885-001C KNOB(B.RELEASE)
101B LY30886-001B BKT(B.RELEASE)
101C QYSLSP2030D SCREW
101D QYSLSP2050D SCREW,X2
101E QYSLSF2055D SPECIAL SCREW,X2
101G LY30002-026A COMPRES. SPRING
101J LY30891-001B CAP(RCA JACK)
101K LY30888-001B HOLDER(LITHIUM)
101L WJM0119-001A E-SI C WIRE C-F
101N LY40081-001A CAP
102 LY20014-001A GRIP BELT
103 LY30018-003A SPECIAL SCREW
! 104 LY30887-001B CAP(JIG)
105 QYSLSP2030D SCREW
106 LY10124-059A FRONT COVER ASSY
106A LY30893-001C HOOD
106B LY31556-001A COVER(HOOD)
106C LY20349-001C GUIDE(SHUTTER)
106D LY30895-001B SHUTTER(1)
106E LY30896-001A SHUTTER(2)
106F YQ43762 SPECIAL SCREW,X2
106G LY41075-001A SLIDER(SHUTTER)ASSY
106H QYSLSF2050Z SCREW,X2
106J QYSLSF2060Z SCREW,X3
106K LY20348-001A DIAL(SHUTTER)
106L LY41081-001D TORSION SPRING
106M LY41128-001B HOLD(SHUTTER)
106N LY41381-001A MARK
106P LY41077-001A LEVER(1)
106Q LY41078-001A LEVER(2)
107 LY10131-019A CASS.COVER(M)ASSY
107A LY30907-001A BUTTON(PUSH)
107B LY40076-002A SPACER,X2
108 LY10133-001C UPPER CASE(M)
109 LY30908-001D BKT(UPPER)ASSY
109A LY30909-001A BKT(STOPPER)
109B LY30910-001C COVER(STOPPER)
109C QYSLSP2030D SCREW,X2
109D QYSLSP2025D SCREW
109E LY41384-001A EARTH PLATE(B)
110 LY10129-0A1A TOP COVER
111 LY20328-001E COVER(VF)
112 LY30892-001B CAP(REAR JACK)
113 LY10120-035B OPERATION UNIT
114 LY10121-001D ZOOM UNIT
115 LY30861-010A MICROPHONE
116 LY30860-001B DC LIGHT ASSY
116A YQ44266 LAMP
117 QYSLSF2055D SPECIAL SCREW
118 QYSLSF2055D SPECIAL SCREW,X3
119 YQ43762-5 SPECIAL SCREW
120 QYSLSF2055D SPECIAL SCREW
121 QYSLSF2055D SPECIAL SCREW
122 QYSLSF2055D SPECIAL SCREW,X2
123 QYSLSF2055D SPECIAL SCREW,X2
124 QYSLSF2090D SCREW
125 QYSLSF2055D SPECIAL SCREW,X2
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
Ozaki-M13A62
GR-AXM225U/UC
