JVC GR-AXM225U Service Manual

FINAL ASSEMBLY <M2>
Note: Mark – is not used. Mark
is same as left.
! 101 LOWER CASE ASSY LY10122-033A LY10122-047A
106 FRONT COVER ASSY LY10124-041A LY10124-059A
106R COVER (LIGHT) LY30934-001A ––
110 TOP COVER LY10129-074A LY10129-0A1A
116 DC LIGHT ASSY ––LY30860-001B
116A LAMP ––YQ44266
! 137 FRAME ASSY LY20372-002B LY20372-004A
137F CONTACT (LIGHT), X2 ––YQ43810
137G E-SI C WIRE C-F ––WJM0118-001A
146 KNOB (LIGHT) ––LY41083-001B
MODEL
ITEM
REF NO.
GR-AXM220U GR-AXM220UC GR-AXM225U GR-AXM225UC
MAIN BOARD ASSEMBLY <01>
PW MAIN BOARD ASSY YB10271UL-02 YB10271UM-03
IC3004 IC ––TC74VHC74FT
Q3005 TRANSISTOR ––DTA144EE
Q6201 TRANSISTOR ––2SA1774/QR/-X
Q6202 TRANSISTOR ––2SD1628/FG/-X
Q6203 TRANSISTOR ––2SC4617/QR/-X
D3002 DIODE ––DAN222
R3033 MG RESISTOR ––NRSA63J-103X
R3035 MG RESISTOR ––NRSA63J-103X
R6201 MG RESISTOR ––NRSA63J-103X
R6202 MG RESISTOR ––NRSA63J-100X
R6203 MG RESISTOR ––NRSA63J-103X
R6205 MG RESISTOR ––NRSA63J-184X
R6206 MG RESISTOR ––NRSA63J-102X
C6201 E CAPACITOR ––NEA71CM-106X
SW503 SLIDE SWITCH ––NSW0092-001X
CN14 CONNECTOR ––QGA1201C2-02X
MODEL
ITEM
REF NO.
GR-AXM220U GR-AXM220UC GR-AXM225U GR-AXM225UC
2
