EN35
USER MAINTENANCE
After Use
1
Turn off the camcorder.
2
Open the LCD monitor fully. Slide EJECT to open the
cassette holder, then remove the cassette.
3
Press PUSH to close and lock the cassette holder.
4
Close and lock the LCD monitor.
5
Slide BATTERY RELEASE to remove the battery pack.
6
Turn the LENS COVER Open/Close Ring to close
the lens cover.
Cleaning The Camcorder
1
To clean the exterior, wipe gently with a soft cloth.
Put the cloth in diluted mild soap and wring it well to
wipe off heavy dirt. Then wipe again with a dry cloth.
2
Open the LCD monitor and wipe gently with a soft
cloth. Be careful not to damage the monitor. Close
the LCD monitor.
3
To clean the lens, blow it with a blower brush, then
wipe gently with lens cleaning paper.
4
To detach the eyepiece, turn it counterclockwise and
pull it out.
5
Remove dust from the viewfinder using a blower
brush.
6
Re-attach the eyepiece and turn it clockwise.
Remove.
PUSH Button
LENS COVER Open/Close Ring
EJECT Switch
Set to “OFF”.
BATTERY RELEASE
NOTES:
●
Avoid using strong cleaning agents such as benzine or alcohol.
●
Cleaning should be done only after the battery pack has been removed or other power units have been
disconnected.
●
Mold may form if the lens is left dirty.
●
When using a cleaner or chemically treated cloth refer to the cautions of each product.
●
When removing the eyepiece, be sure to hold the viewfinder securely.
