Controls
a Menu Wheel [MMENU/VOL.] (墌 pg. 25)
Speaker Volume Control [MMENU/VOL.] (墌 pg. 14)
b Snapshot Button [SNAPSHOT] (墌 pg. 18, 31)
c Power Zoom Lever [T/W] (墌 pg. 12)
d Manual Focus Button [FOCUS] (墌 pg. 32)
Blank Search Button [BLANK SRCH] (墌 pg. 14)
e Diopter Adjustment Control (墌 pg. 9)
f Recording Start/Stop Button (墌 pg. 11)
g Power Switch [A, M, PLAY, OFF] (墌 pg. 8)
h Lock Button (墌 pg. 8)
i Stop Button [8] (墌 pg. 14)
j Rewind Button [ 3 ] (墌 pg. 14)
Night Button [NIGHT] (墌 pg. 29)
k Play/Pause Button [4/9] (墌 pg. 14)
l Fast-Forward Button [ 5 ] (墌 pg. 14)
Backlight Compensation Button [BACKLIGHT]
(墌 pg. 33)
m Index Button [INDEX] (GR-D93/73 only) (墌 pg. 20)
n VIDEO/MEMORY Switch (GR-D93/73 only) (墌 pg. 8)
o Information Button [INFO] (GR-D93/73 only)
(墌 pg. 21)
p Battery Release Switch [BATT.RELEASE] (墌 pg. 6)
q Cassette Open/Eject Switch [OPEN/EJECT]
(墌 pg. 10)
r White LED Light Switch [LIGHT] (墌 pg. 29)
s Monitor Opening Button (墌 pg. 12)
For models without button, simply pull on bottom end
of LCD monitor to open.
Connectors
T S-Video Input**/Output Connector [S-VIDEO]
(墌 pg. 17, 34)
U USB (Universal Serial Bus) Connector (GR-D93/73
only) (墌 pg. 36)
V Digital Video Connector [DV IN/OUT] (i.Link*)
(墌 pg. 35, 36)
W Audio/Video Input**/Output Connector [AV]
(墌 pg. 17, 34)
X DC Input Connector [DC] (墌 pg.6,7)
* i.Link refers to the IEEE1394-1995 industry specification
and extensions thereof. The logo is used for products
compliant with the i.Link standard.
**GR-D93/73 only
Indicators
C POWER/CHARGE Lamp (墌 pg.8,11)
Other Parts
a Shoulder Strap Eyelet (墌 pg. 5)
b Battery Pack Mount (墌 pg. 7)
c Grip Strap (墌 pg. 7)
d LCD Monitor (墌 pg. 12, 13)
e Speaker (墌 pg. 14)
f Stud Hole (墌 pg. 9)
g Tripod Mounting Socket (墌 pg. 9)
h Card Cover [MEMORY CARD] (GR-D93/73 only)
(墌 pg. 10)
i Cassette Holder Cover (墌 pg. 10)
j Stereo Microphone (墌 pg. 37)
k White LED Light (墌 pg. 29)
l Viewfinder (墌 pg. 9)
m Remote Sensor (墌 pg. 15)
n Camera Sensor
(Be careful not to cover this area, a sensor necessary
for shooting is built-in here.)
