EN
9
GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
Controls
1
Rewind Button [1
] (
pg. 20)
Left Button [
1
] (
pg. 14)
Quick Review Button [QUICK REVIEW]
(
pg. 19)
2
Set Button [SET] (
pg. 14)
Data Battery Button [DATA] (
pg. 13)
3
Stop Button [7
] (
pg. 20)
Backlight Compensation Button
[BACKLIGHT] (
pg. 28)
Down Button [
4
] (
pg. 22)
4
Play/Pause Button [6
] (
pg. 20)
Manual Focus Button [FOCUS] (
pg. 27)
Up Button [3] ( pg. 22)
5Wide Button [WIDE] ( pg. 26)
Blank Search [BLANK] ( pg. 20)
6Menu Button [MENU] ( pg. 22)
7Fast-Forward Button [¡] ( pg. 20)
Right Button [2] ( pg. 14)
Night Button [NIGHT] ( pg. 26)
8Diopter Adjustment Control ( pg. 15)
9Auto Button [AUTO] ( pg. 14)
!Snapshot Button [SNAPSHOT] ( pg. 26)
"Power Zoom Lever [T/W] ( pg. 18)
Speaker Volume Control [VOL. +, –]
( pg. 20)
#Battery Release Button [PUSH BATT.]
( pg. 12)
$Recording Start/Stop Button ( pg. 17)
%Power Switch [REC, OFF, PLAY] ( pg. 14)
&Lock Button ( pg. 14)
(Cassette Open/Eject Switch [OPEN/EJECT]
( pg. 16)
Connectors
The connectors are located beneath the covers.
)Audio/Video Output Connector [AV]
( pg. 21, 32)
~S-Video Output Connector [S] ( pg. 21, 32)
+DC Input Connector [DC] ( pg. 12)
,Digital Video Connector [DV IN/OUT] (i.LINK*)
( pg. 33, 34)
* i.LINK refers to the IEEE1394-1995 industry
specification and extensions there of. The logo
is used for products compliant with the i.LINK
standard.
Indicators
ã
POWER/CHARGE Lamp ( pg. 12, 17)
Other Parts
å
LCD Monitor ( pg. 17)
ç
Viewfinder ( pg. 15)
é
Battery Pack Mount ( pg. 13)
è
Shoulder Strap Eyelet ( pg. 11)
ê
Speaker ( pg. 20)
ë
Grip Strap ( pg. 15)
í
Lens
ì
Camera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
î
Stereo Microphone
ï
Stud Hole ( pg. 16)
ñ
Tripod Mounting Socket ( pg. 16)
ó
Cassette Holder Cover ( pg. 16)
GR-D350AG_EN.book Page 9 Wednesday, December 28, 2005 8:24 AM
