(No.86733)3-7
2. PARTS LIST
PACKING AND ACCESSORY ASSEMBLY <M1>
FINAL ASSEMBLY <M2>
 Symbol No. Part No. Part Name Description Local
1 LY33063-013A PACKING CASE
2 LY33065-001B CUSHION A
2 LY33065-001C CUSHION B,C,D
3 LY30023-027A POLY BAG
4 YQM30061-3 POLY BAG A
4 QPA02003506 POLY BAG 20cm x 35cm B,C,D
 5 LYT1145-001A INST BOOK (ENGLISH) A
 5 LYT1145-003A INST BOOK (FRENCH) B
 5 LYT1145-004A INST BOOK (DUTCH) B
 5 LYT1145-005A INST BOOK (SPANISH) B
 5 LYT1145-006A INST BOOK (ITALIAN) B
 5 LYT1145-002A INST BOOK (GERMAN) B,C
 5 LYT1145-007A INST BOOK (DANISH) C
 5 LYT1145-008A INST BOOK (FINNISH) C
 5 LYT1145-009A INST BOOK (SWEDISH) C
 5 LYT1145-010A INST BOOK (NORWEGIAN) C
 5 LYT1145-011A INST BOOK (RUSSIAN) D
 5 LYT1145-012A INST BOOK (CZECH) D
 5 LYT1145-013A INST BOOK (POLISH) D
 5 LYT1145-014A INST BOOK (HUNGARIAN) D
6 LYT1085-001A INST BOOK (SOFT.ENGLISH) A
6 LYT1085-003A INST BOOK (SOFT.FRENCH) B
6 LYT1085-004A INST BOOK (SOFT.DUTCH) B
6 LYT1085-005A INST BOOK (SOFT.SPANISH) B
6 LYT1085-006A INST BOOK (SOFT.ITALIAN) B
6 LYT1085-002A INST BOOK (SOFT.GERMAN) B,C
6 LYT1085-007A INST BOOK (SOFT.DANISH) C
6 LYT1085-008A INST BOOK (SOFT.FINNISH) C
6 LYT1085-009A INST BOOK (SOFT.SWEDISH) C
6 LYT1085-010A INST BOOK (SOFT.NORWEGIAN) C
6 LYT1085-011A INST BOOK (SOFT.RUSSIAN) D
7 BT-54008-4 WARRANTY CARD A
7 BT-54013-5 WARRANTY CARD B,C,D
8 YU30878 REGIST. CARD A
9 LYT0194-001B Q.CARD(JUK) A
20 QPA01703005 POLY BAG 17cm x 30cm
23 QAM0451-001 USB CABLE
24 QQR0491-002 FERRITE CORE TDK (BLACK)
25 QAM0212-001 A/V CABLE
26 QQR0918-002 CORE FILTER
 27 LY20955-001C AC ADAPTER AP-V13E
 27 or LY20956-001B AC ADAPTER AP-V11E
28 QQR0917-002 CORE FILTER
 29 QMPP110-190-JR POWER CORD(EK) 1.9m BLACK A
 29 QMPL120-190-JR POWER CORD(EU) 1.9m BLACK B,C,D
30 QPA02503505P POLY BAG 25cm x 35cm
 31 LY32566-001A BATT.PACK ASSY BN-V408U-B
32 LY20186-004A SHOULDER STRAP
33 LY21020-001A REMOCON RM-V718U
34 QQR0491-002 FERRITE CORE TDK (BLACK)
36 LY44002-001B CAP(HOOD)ASSY
37 LY32210-051A CD ROM ASSY
39 QAM0404-002 MEMORY CARD*
40 QQR0491-002 FERRITE CORE TDK (BLACK)
41 QAM0302-001 ADAPTOR PLUG
*NOTE:
DATA FILE is not contained in MEMORY CARD of the service part.
 Symbol No. Part No. Part Name Description Local
101 LY20941-004M U.CASE(2.5)ASSY
101A LY40664-001A SPACER (x2)
101B LY33051-001D COVER(SD)
101C LY43977-001A SHAFT
101D LY43978-001A SPRING
101E LY33042-001A C.LABEL(VF)
101F LY30030-0F2A SPACER(A)
102 LY30018-0D6A SPECIAL SCREW (x2)
103 LY33044-001D BKT(HINGE2.5)
104 LY30018-096A SPECIAL SCREW (x2)
105 QAS0126-001 SPEAKER
106 LY30018-017A SPECIAL SCREW (x2)
107 LY33048-001A KNOB(SLIDE)
108 LY30018-059A SPECIAL SCREW (x4)
109 LY33049-002A COVER(UPPER2.5)
110 LY30018-056A SPECIAL SCREW (x2)
111 LY30018-0E6A SPECIAL SCREW (x2)
112 LY33050-002C COVER(JIG)
113 QUQ105-1007AA FFC WIRE MONI CN 762-MAIN CN103
114 QUQ105-4007AA FFC WIRE MONI CN761-MAIN CN101
115 LY33009-001A ORNAMENT(2.5 1)
116 LY30018-0E6A SPECIAL SCREW (x2)
117 LY30018-0A1A SPECIAL SCREW
118 LY30018-096A SPECIAL SCREW (x2)
119 LY30018-096A SPECIAL SCREW
120 LY33025-001B TOP COVER ASSY
120A LY40162-001A BKT
121 LY30018-096A SPECIAL SCREW
122 LY30018-096A SPECIAL SCREW
123 LY44187-003A STICKER(2)
125 LY30018-0E6A SPECIAL SCREW (x2)
126 LY30030-0E3B SPACER(A)
127 LY30030-0E5A SPACER(A)
135 LY20943-002E F.COVER ASSY
135A LY33056-001B HOOD
135B LY33057-001A RING
135C LY33058-001A HOOD(SCREW)
135D LY33059-001B BKT(FRONT)
135E LY44186-002A STICKER(1)
135F LY30018-0E6A SPECIAL SCREW
135G LY30018-052A SPECIAL SCREW (x3)
136 LY20944-001B MIC
137 LY30018-0G6A SPECIAL SCREW
 145 LY20938-001E REAR UNIT
146 LY30018-0G6A SPECIAL SCREW (x2)
147 LY30018-0J1A SPECIAL SCREW (x2)
148 LY30018-0H3A SPECIAL SCREW
155 LY20935-002E LOWER CASE ASSY
155A LY33402-001A COVER(LOWER)
155B LY30018-0E6A SPECIAL SCREW (x2)
156 LY20939-001F ARM ASSY
156A LY30002-046B COMPRES. SPRING (x2)
156B LY43973-001A TENSION SPRING
157 QUQ105-2203AA FFC WIRE JACK CN501-MAIN CN102
158 LY30018-096A SPECIAL SCREW
159 LY30018-059A SPECIAL SCREW (x2)
160 LY30018-096A SPECIAL SCREW (x2)
161 LY10453-001E ZOOM UNIT
162 LY30018-0E6A SPECIAL SCREW
163 LY33395-001A BRACKET(ZOOM)
164 LY30018-059A SPECIAL SCREW
165 LY20937-003B C.COVER ASSY
165A LY33027-001B KNOB(LOCK)
165B LY33028-001A HOLDER(LOCK)
165C LY33397-001A HOOK(G.B)
165D LY33039-001A BKT(G.BELT)
165E LY20945-003A GRIP BELT
165F LY44178-001A SHEET(C.COV)
165G LY30018-0E6A SPECIAL SCREW
165H QYSLSF2040D TAP SCREW 2mm x 4mm(x2)
165J QYSLSF2040D TAP SCREW 2mm x 4mm(x2)
165K QYSLSF2040D TAP SCREW 2mm x 4mm
165L LY30018-0H1A SPECIAL SCREW (x2)
166 LY30018-0K3A SPECIAL SCREW (x2)
167 LY30018-096A SPECIAL SCREW (x2)
168 LY30018-059A SPECIAL SCREW (x2)
169 LY31019-001A BASE
170 LY30018-0E6A SPECIAL SCREW (x2)
171 LY33396-001B HOLDER(JACK)
172 LY30018-0E6A SPECIAL SCREW
173 LY33037-001B COVER(ZOOM)
174 LY30018-084A SPECIAL SCREW (x3)
175 LY33029-001B COVER(ADJUST)
176 LY33024-001C COVER(JACK)
178 LY30018-017A SPECIAL SCREW
191 LY33019-001B BKT(MECHA)ASSY
 Symbol No. Part No. Part Name Description Local
MODEL MARK
GR-D70EK A
GR-D70EX B
MODEL MARK
GR-D70EY C
GR-D70EZ D
