1-2 (No.YF219)
SPECIFICATION
Camcorder
AC Adapter
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change without
notice.
For General Power supply DC 11 V (Using AC Adapter)
DC 7.2 V (Using battery pack)
Power consumption Approx. 2.6 W
Dimensions (W × H × D) 71 mm × 77 mm × 117 mm(2-8" × 3" × 4.6")
Weight Approx. 385 g (0.84 lbs) (without battery, cassette and lens cap)
Approx. 455 g (1.0 lbs) (incl. battery, cassette and lens cap)
Operating temperature 0°C to 40°C (32°F to 104°F)
Operating humidity 35% to 80%
Storage temperature -20°C to 50°C (-4°F to 122°F)
Pickup 1/6" CCD
Lens F 2.0 to 4.1, f = 2.3 mm to 69 mm, 30:1 power zoom lens (GR-DA30US)
F 2.0 to 4.7, f = 2.3 mm to 78.2 mm, 34:1 power zoom lens (GR-DA30UC)
Filter diameter Ø27 mm
LCD monitor 2.4" diagonally measured, LCD panel/TFT active matrix system
Speaker Monaural
LED Light Effective distance: 1.5 m (5 ft)
For Digital Video
Camera
Format DV format (SD mode)
Signal format NTSC standard
Recording/Playback
format
Video Digital component recording
Audio PCM digital recording, 32 kHz 4-channel (12-BIT), 48 kHz 2-channel (16-BIT)
Cassette Mini DV cassette
Tape speed SP: 18.8 mm/s, LP: 12.5 mm/s
Maximum recording time
(using 80 min. cassette)
SP: 80 min., LP: 120 min.
For Connectors AV Video output 1.0 V (p-p), 75Ω, analog
Audio output 300 mV (rms), 1 kΩ, analog, stereo
DV Input/output 4-pin, IEEE 1394 compliant
Power requirement AC 110 V to 240 V, 50 Hz/60 Hz
Output DC 11 V, 1 A
