EN95
For Connectors
AV
Video output :1 V
(
p-p
)
, 75 Ω, analogue
Video input (GR-DV2000 only) : 0.5 V
(
p-p
)
– 2.0 V
(
p-p
)
, 75 Ω, analogue
Audio output : 308 mV (rms), 1 kΩ, analogue, stereo
Audio input (GR-DV2000 only) : 308 mV (rms), 50 kΩ, analogue, stereo
DV
Output : 4-pin, IEEE 1394 compliant
Input (GR-DV2000 only) : 4-pin, IEEE 1394 compliant
PHONE
Headphone output : ø3.5 mm, stereo
MIC
External microphone input : 459 µV (rms), high impedance unbalanced, ø3.5 mm (stereo)
PRINTER : For an optional video printer equipped with a PRINT DATA
connector
AC Power Adapter/Charger AA-V40EG or AA-V40EK
Power requirement : AC 110 V to 240 V`, 50 Hz/60 Hz
Power consumption : 23 W
Output
Charge : DC 7.2 V
, 1.2 A
VTR : DC 6.3 V
, 1.8 A
Dimensions (W x H x D) : 68 mm x 38 mm x 110 mm
Weight
AA-V40EG : Approx. 260 g
AA-V40EK : Approx. 340 g
Jack Box CU-V504U
For General
Dimensions (W x H x D) : 37.5 mm x 18.5 mm x 55 mm
Weight : Approx. 30 g
For Connectors
USB : TYPE B
S-VIDEO : Y: 1 V (p-p), 75 Ω, analogue output
C: 0.29 V (p-p), 75 Ω, analogue output
EDIT : ø3.5 mm, 2-pole
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
