JVC GR-DVA10 Technical Guide

2-52
•
••
•
Deck CPU (IC1401: MN103004KRH) pin functions (5/5)
Pin No. Label In/Out
Description
140 -
138 -
142 -
139 -
141 -
137 -
124 VDDH - Power supply (REG_3V)
122 -
123 -
121 -
125 -
106 VPP - Power supply (REG_3V)
107 BR(L) - H: fixed
105 VSS - GND
109 ANA_CLK Out Serial clock (To DV_ANA: IC3301)
108 ANA_IN Out Serial data bus output (To DV_ANA: IC3301)
93 ANA_OUT In Serial data bus input (From DV_ANA: IC3301)
91 MDA_CLK Out Serial clock (To MDA: IC1601)
94 MDA_IN Out Serial bus data output (To MDA: IC1601)
90 VDD Power supply (REG_3V)
92 MDA_OUT In Serial bus data input (From MDA: IC1601)
89 SYS_CLK In Serial clock (From SYSCON CPU: IC1001)
78 SYS_IN Out Serial bus data output (To SYSCON CPU: IC1001)
74 SYS_OUT In Serial bus data input (From SYSCON CPU: IC1001)
76 - - Not used
73 VSS - GND
77 TXD Out RS232C output
59 RXD In RS232C input
75 OSD_CLK Out Serial clock (To OSD: IC1002)
58 OSD_DATA Out Serial bus data (To OSD: IC1002)
60 - - Not used
57 MIC_SCL Out Serial clock for MIC
43 VDDH Power supply (REG_3V)
42 MIC_SDA In Serial data for MIC
44 -
41 -
- Not used
- Not used
Not used-
Table 2-7-1 Deck CPU (IC1401: MN103004KRH) pin functions (5/5)
