Controls
1 Monitor Open Button [PUSH OPEN] ...... 墌 pg. 15
2 Dioptre Adjustment Control .................... 墌 pg. 10
3 Battery Release Button
[BAT. RELEASE] ...................................... 墌 pg. 8
4 • MENU Wheel [+, –, PUSH] .................. 墌 pg. 32
• LCD Monitor BRIGHT (Brightness)
Control [+, –] ........................................ 墌 pg. 15
5 Snapshot Button
[SNAPSHOT] ......................................... 墌 pg. 28
6 • Power Zoom Lever [T/W] ..................... 墌 pg. 17
• Speaker Volume Control [VOL.] ........... 墌 pg. 19
7 • FOCUS Button ..................................... 墌 pg. 29
• BLANK SEARCH Button ...................... 墌 pg. 22
8 • Stop Button [5] .................................... 墌 pg. 19
• BACKLIGHT Button ............................. 墌 pg. 30
9 • Rewind Button [
2
] ............................. 墌 pg. 19
• NIGHT SCOPE Button ......................... 墌 pg. 24
0 Play/Pause Button [
4
/6] ........................ 墌 pg. 19
! Fast-Forward Button [
3
] ...................... 墌 pg. 19
@ Power Switch
[
, , PLAY, OFF] .............................. 墌 pg. 16
# Recording Start/Stop Button .................. 墌 pg. 15
$ Lock Button ............................................ 墌 pg. 16
% OPEN/EJECT Switch ............................. 墌 pg. 12
Connectors
The connectors
^
to
*
are located beneath a cover.
^
Audio/Video Output Connector
[AV] ................................................... 墌 pg. 20, 38
&
S-Video Output Connector
[S-VIDEO] ........................................ 墌 pg. 20, 38
*
DC Input Connector ............................. 墌 pg. 8, 9
(
Digital Video Connector
[DV OUT] (i.Link*) ............................ 墌 pg. 39, 45
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof.
The
logo is used for products compliant with
the i.Link standard.
Indicators
)
CHARGE Lamp ........................................ 墌 pg. 8
q
Power Lamp ..................................... 墌 pg. 15, 16
Other Parts
w
Stereo Microphone ................................. 墌 pg. 43
e
Viewfinder ............................................... 墌 pg. 10
r
Viewfinder Cleaning Hatch ..................... 墌 pg. 53
t
Shoulder Strap Eyelets .......................... 墌 pg. 10
y
Grip Strap ............................................... 墌 pg. 10
u
• Remote Sensor .................................... 墌 pg. 40
• Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
i
LCD Monitor ..................................... 墌 pg. 15, 16
o
Speaker .................................................. 墌 pg. 19
p
Battery Pack Mount .................................. 墌 pg. 8
Q
Stud Hole ............................................... 墌 pg. 10
W
Tripod Mounting Socket ......................... 墌 pg. 10
