EN67
SPECIFICATIONS
Camcorder
For General
Power supply : DC 11.0 V (Using AC Adapter)
DC 7.2 V (Using battery pack)
Power consumption
LCD monitor off, viewfinder on : Approx. 4.3 W
LCD monitor on, viewfinder off : Approx. 5.3 W
Dimensions (W x H x D) : 83 mm x 97 mm x 188 mm (3-5/16" x 3-7/8" x 7-7/16")
(with the LCD monitor closed and the viewfinder pushed down)
Weight : Approx. 590 g (1.3 lbs)
Operating temperature :0°C to 40°C (32°F to 104°F)
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C (–4°F to 122°F)
Pickup : 1/4" CCD
Lens : F 1.8, f = 3.6 mm to 36 mm, 10:1 power zoom lens
Filter diameter : ø37 mm
LCD monitor : 2.5" diagonally measured, LCD panel/TFT active matrix system
Viewfinder : Electronic viewfinder with 0.24" black/white LCD
Speaker : Monaural
For Digital Video Camera
Format : DV format (SD mode)
Signal format : NTSC standard
Recording/Playback format : Video: Digital component recording
: Audio: PCM digital recording, 32 kHz 4-channel (12-bit),
48 kHz 2-channel (16-bit)
Cassette : Mini DV cassette
Tape speed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time : SP: 80 min.
(using 80 min. cassette) LP: 120 min.
For Connectors
S-Video : Y : 1 V (p-p), 75 W, analog
C : 0.29 V (p-p), 75 Ω, analog
AV
Video output :1 V
(
p-p
)
, 75 Ω, analog
Audio output : 300 mV (rms), 1 kΩ, analog, stereo
DV
Output/input : 4-pin, IEEE 1394 compliant
PC (DIGITAL PHOTO) : ø2.5 mm, 3-pole
JLIP : ø3.5 mm, 4-pole
AC Adapter AP-V10U
Power requirement
U.S.A. and Canada : AC 120 V`, 60 Hz
Other countries : AC 110 V to 240 V`, 50 Hz/60 Hz
Output : DC 11 V , 1 A
Dimensions (W x H x D) : 59 mm x 31 mm x 84 mm (2-3/8" x 1-1/4" x 3-5/16")
Weight : Approx. 130 g (0.29 lbs.)
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
