# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
5-17
C6230 NCB21CK-105X CAPACITOR 1µF,16V
C6231 NCBA1CK-103W CAPACITOR 0.01µF,16V
C6701 NCB21CK-105X CAPACITOR 1µF,16V
C6703 NCB21CK-105X CAPACITOR 1µF,16V
L1002 NQL315K-100X COIL 10µH
L1401 NQR0006-001X FERRITE BEAD
L2001 NQL315K-100X COIL 10µH
L2002 NQL38DK-220X COIL 22µH
L2101 NQR0269-013X FERRITE BEAD
L2102 NQR0269-013X FERRITE BEAD
L2103 NQR0269-013X FERRITE BEAD
L2501 NQL38DK-220X COIL 22µH
L3001 NQR0129-002X FERRITE BEAD
L3002 NQR0129-002X FERRITE BEAD
L3004 NQR0006-001X FERRITE BEAD
L3005 NQR0006-001X FERRITE BEAD
L3006 NQR0006-001X FERRITE BEAD,F,G
L3007 NQL085J-2R2X COIL 2.2µH
L3008 NQL085J-120X COIL 12µH
L3012 NQR0129-002X FERRITE BEAD,A,B,C,D,E
L3014 NQL38DK-100X COIL 10µH
L3015 NQR0006-001X FERRITE BEAD
L3501 NQR0129-002X FERRITE BEAD
L3502 NQL402M-100X COIL 10µH
L3503 NQR0006-001X FERRITE BEAD
L3504 NQR0006-001X FERRITE BEAD
L3505 NQR0006-001X FERRITE BEAD
L3701 NQL38DK-100X COIL 10µH
L3731 NQL085J-6R8X COIL 6.8µH
L3732 NQL085J-6R8X COIL 6.8µH
L3801 NQR0129-002X FERRITE BEAD
L3802 NQR0129-002X FERRITE BEAD
L3803 NQR0006-001X FERRITE BEAD
L3804 NQL38DK-100X COIL 10µH
L4201 NQL402M-100X COIL 10µH
L4301 NQR0129-002X FERRITE BEAD
L4302 NQR0129-002X FERRITE BEAD
L4303 NQR0129-002X FERRITE BEAD
L4304 NQR0129-002X FERRITE BEAD
L4305 NQR0129-002X FERRITE BEAD
L4802 NQL302N-100X COIL 10µH
L4851 NQR0129-002X FERRITE BEAD
L4852 NQL315K-100X COIL 10µH
L4853 NQL315K-100X COIL 10µH
L5001 NQR0129-002X FERRITE BEAD
L5002 NQL045K-100X COIL 10µH
L5003 NQL045K-100X COIL 10µH
L5004 NQL045K-100X COIL 10µH
L5005 NQR0129-002X FERRITE BEAD
L5006 NQL045K-100X COIL 10µH
L5007 NQR0129-002X FERRITE BEAD
L6101 NQLZ011-4R7X COIL 4.7µH
L6102 NQLZ011-4R7X COIL 4.7µH
L6201 NQL52EM-390X COIL 39µH
L6202 NQL52EM-390X COIL 39µH
L6203 NQL52EM-390X COIL 39µH
L6204 NQL144K-220X COIL 22µH
L6205 NQL64EM-220X COIL 22µH
L6206 NQLZ011-470X COIL 47µH
L6207 NQLZ011-470X COIL 47µH
L6208 NQLZ011-221X COIL 220µH
L6701 NQLZ010-100X COIL 10µH
X1001 NAX0474-001X C OSCILLATOR
X1002 NAX0325-001X CRYSTAL RESONATOR
X1401 NAX0204-001X CRYSTAL RESONATOR
X3002 NAX0480-001X CRYSTAL RESONATOR
X4301 NAX0356-001X CXO
WR1 WJT0065-001A E-CARD WIRE,CN102-JACK CN502
WR2 WJJ0268-001A E-SI C WIRE C-C,CN104-REAR CN552
CN101 QGF0508F1-40X FPC CONNECTOR
CN102 QGF0505F2-24X FPC CONNECTOR
CN103 QGF0503C1-12V FFC/FPC CONNECTOR
CN104 QGA1002C1-06X CONNECTOR
CN105 QGB0801K2-30X CONNECTOR
CN106 QGA1201C2-07X CONNECTOR
CN107 QGF0503C1-20X FFC/FPC CONNECTOR
CN108 QGF0512C1-24X FPC CONNECTOR
CN109 QGF0507F4-15X FFC/FPC CONNECTOR
CN110 QGF0505F1-08X FPC CONNECTOR
CN111 QGB0501L1-A0X CONNECTOR
CN112 QGF0505F2-18X FPC CONNECTOR
CN113 QGF0508F1-33X FPC CONNECTOR
! F6101 NMFZ007-2R0X-K FUSE T2.0A,50V
OT1 LY43491-001A SHEET(MAIN)
OT2 LY43549-001A SHEET(MECHA)
OT3 LY43770-001A SPACER(CAPSTAN)
OT4 LY43770-002A SPACER(CAPSTAN)
OT5 LY30030-012A SPACER(A),F,G
SD1 LY32080-001A SHIELD CASE
E. & O. E. No. 86683
(Sanwa)-M2D229/249
GR-DVL820A/A-S/EA/SH, DVL1020A/EA/SH
