JVC GR-DVL820A

SERVICE MANUAL
No. 86670
February 2002
SPECIFICATIONS
DIGITAL VIDEO CAMERA
Printed in Japan
This service manual is printed on 100% recycled paper.
COPYRIGHT © 2002 VICTOR COMPANY OF JAPAN, LTD.
GR-DVL765EG
No. 86670
GR-DVL765EG
VICTOR COMPANY OF JAPAN, LIMITED
VIDEO DIVISION
S40894
(The specifications shown pertain specifically to the model GR-DVL160,DVL167,DVL365,
DVL367,DVL567,DVL765,DVL767,DVL865,DVL867)
Digital Still Camera Function (GR-DVL867/DVL865/DVL767/DVL765/DVL567/DVL367/DVL365 only)
Storage media : SD Memory Card/MultiMediaCard
Compression system : Still image : JPEG (compatible)
Moving image : MPEG4 (compatible)
File size : 3 modes (1280 X 960 pixels*, 1024 x 768 pixels,
640 x 480 pixels)
Picture quality : 2 modes (FINE/STANDARD)
Approximate number of
storable images : 墌 pg. 27.
* GR-DVL867/DVL865/DVL767/DVL765 only.
Connectors
S-Video
Output : Y:1 V (p-p), 75 Ω, analogue
C:0.29 V (p-p), 75 Ω, analogue
AV
Video output : 1 V (p-p), 75 Ω, analogue
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
DV
Output : 4-pin, IEEE 1394 compliant
Input (GR-DVL867/DVL767/ : 4-pin, IEEE 1394 compliant
DVL567/DVL367/DVL167 only)
USB (GR-DVL867/DVL865/
DVL767/DVL765/DVL567/
DVL367/DVL365 only) : 5-pin
PC (GR-DVL167/DVL160 only) : ø2.5 mm, 3-pole
EDIT (GR-DVL867/DVL865/
DVL767/DVL765/DVL567/
DVL367/DVL365 only) : ø3.5 mm, 2-pole
JLIP (GR-DVL167/DVL160 only) : ø3.5 mm, 4-pole
AC Adapter
Power requirement : AC 110 V to 240 V`, 50 Hz/60 Hz
Output : DC 11 V , 1 A
Specifications shown are for SP mode unless otherwise indicated.
E & O.E. Design and specifications subject to change without notice.
Camcorder
General
Power supply : DC 11.0 V (Using AC Adapter)
DC 7.2 V
(Using battery pack)
Power consumption
LCD monitor off, viewfinder on : Approx. 4.5 W (GR-DVL867/DVL865/DVL767/DVL765)
Approx. 4.3 W (GR-DVL567/DVL367/DVL365/DVL167/DVL160)
LCD monitor on, viewfinder off : Approx. 5.7 W (GR-DVL867/DVL865/DVL767/DVL765)
Approx. 5.3 W (GR-DVL567/DVL367/DVL365/DVL167/DVL160)
Video light : Approx. 2.8 W (GR-DVL867/DVL865/DVL767/DVL765)
Approx. 3.5 W (GR-DVL567/DVL367/DVL365/DVL167/DVL160)
Dimensions (W x H x D) : 79 mm x 89 mm x 184 mm (GR-DVL867/DVL865/DVL767/DVL765)
79 mm x 89 mm x 167 mm
(GR-DVL567/DVL367/DVL365/DVL167/DVL160)
(with the LCD monitor closed and the viewfinder pushed down)
Weight : Approx. 580 g (GR-DVL867/DVL865)
Approx. 570 g (GR-DVL767/DVL765/DVL567)
Approx. 560 g (GR-DVL367/DVL365)
Approx. 550 g (GR-DVL167/DVL160)
Operating temperature : 0°C to 40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C
Pickup : 1/3.8" CCD (GR-DVL867/DVL865/DVL767/DVL765)
1/4" CCD (GR-DVL567/DVL367/DVL365/DVL167/DVL160)
Lens : F 1.8, f = 3.8 mm to 38 mm, 10:1 power zoom lens
(GR-DVL867/DVL865/DVL767/DVL765)
F 1.8, f = 3.6 mm to 36 mm, 10:1 power zoom lens
(GR-DVL567/DVL367/DVL365/DVL167/DVL160)
Filter diameter : ø37 mm
LCD monitor : 3.5" diagonally measured, LCD panel/TFT active matrix system
(GR-DVL867/DVL865/DVL567)
2.5" diagonally measured, LCD panel/TFT active matrix system
(GR-DVL767/DVL765/DVL367/DVL365/DVL167/DVL160)
Viewfinder : Electronic viewfinder with 0.24" black/white LCD
Speaker : Monaural
Digital Video Camera
Format : DV format (SD mode)
Signal format : PAL standard
Recording/Playback format : Video: Digital component recording
:
Audio: PCM digital recording, 32 kHz 4-channel (12-bit), 48 kHz 2-channel (16-bit)
Cassette : Mini DV cassette
Tape speed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time : SP: 80 min.
(using 80 min. cassette) LP: 120 min.
