2-13
11e
24
(S11)
22
(S11)
20
(S11)
Note 11
21
(S11)
19
(S11)
18
(S11)
(W11)
23
(S11)
11d
11c
11b
11a
Fig. 2-4-15
11. 11a Catcher (T) assembly/ 11b Capstan motor
11c Charge arm assembly/ 11d Sub cam gear
11e PWB holder
Note 11:
The following figure shows how to put the charge arm as-
sembly and sub cam gear assembly together.
11d
11c
