(No.YF034)3-17
FRONT BOARD ASSEMBLY <04>
MONITOR BOARD ASSEMBLY <05>
C1606 NCBA1HK-152W C CAPACITOR 1500pF 50V K
C1607 NCBA1CK-473W C CAPACITOR 0.047uF 16V K
C1614 NBE91AM-475X TA E CAPACITOR 4.7uF 10V M
C1618 NCBA1HK-222W C CAPACITOR 2200pF 50V K
C1619 NCBA1HK-222W C CAPACITOR 2200pF 50V K
C1620 NCBA1HK-222W C CAPACITOR 2200pF 50V K
C1621 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C1622 NCBA1CK-223W C CAPACITOR 0.022uF 16V K
C1623 NCBA1AK-473W C CAPACITOR 0.047uF 10V K
C1624 NCBA1CK-103W C CAPACITOR 0.01uF 16V K
C1625 NDCA1HJ-101W C CAPACITOR 100pF 50V J
C1626 NCBA1EK-472W C CAPACITOR 4700pF 25V K
C1627 NCBA1EK-472W C CAPACITOR 4700pF 25V K
C1628 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C1629 NCJ31EK-224X-A C CAPACITOR 0.22uF 25V K
C1630 NCJ31EK-224X-A C CAPACITOR 0.22uF 25V K
C1631 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M
C1632 NCB21CK-474X C CAPACITOR 0.47uF 16V K
C1633 NCB30JK-474X C CAPACITOR 0.47uF 6.3V K
R1601 NRSA6AJ-681W MG RESISTOR 680
Ω 1/16W J
R1602 NRSA6AJ-124W MG RESISTOR 120k
Ω 1/16W J
R1603 NRSA6AJ-472W MG RESISTOR 4.7k Ω 1/16W J
R1604 NRSA6AJ-104W MG RESISTOR 100k Ω 1/16W J
R1610 NRSA6AJ-391W MG RESISTOR 390 Ω 1/16W J
R1611 NRSA6AJ-391W MG RESISTOR 390 Ω 1/16W J
R1612 NRSA6AJ-104W MG RESISTOR 100k Ω 1/16W J
R1613 NRSA6AJ-102W MG RESISTOR 1k Ω 1/16W J
R1614 NRZ0072-R330X MG RESISTOR 0.33 Ω 1/4W F
R1616 NRSA6AD-392W MG RESISTOR 3.9k Ω 1/16W D
R1617 NRZ0072-R330X MG RESISTOR 0.33 Ω 1/4W F
R1620 NRSA6AJ-683W MG RESISTOR 68k Ω 1/16W J
R1621 NRSA6AJ-103W MG RESISTOR 10k Ω 1/16W J
R1622 NRSA6AJ-103W MG RESISTOR 10k Ω 1/16W J
R1624 NRSA6AD-183W MG RESISTOR 18k Ω 1/16W D
R1625 NRSA6AD-681W MG RESISTOR 680 Ω 1/16W D
R1629 NRSA6AJ-564W MG RESISTOR 560k Ω 1/16W J
R1630 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R1631 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R1635 NRSA6AJ-332W MG RESISTOR 3.3k Ω 1/16W J
R1636 NRSA6AJ-123W MG RESISTOR 12k Ω 1/16W J
R1637 NRSA6AJ-154W MG RESISTOR 150k Ω 1/16W J
R1638 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R1639 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R1640 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R1641 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
R1642 NRSA6AJ-0R0W MG RESISTOR 0 Ω 1/16W J
L1601 NQL382M-100X COIL 10uH M
CN301 QGF0532F2-18X CONNECTOR
CAPSTAN FFC/FPC (1-18)
CN302 QGF0532F2-11X CONNECTOR DRUM MOTOR FFC/FPC (1-11)
CN303 QGF0532F2-06X CONNECTOR R.ENCODER FFC/FPC (1-6)
CN304 QGF0517F2-06X CONNECTOR LOAD.MOTOR FFC/FPC (1-6)
CN305 QGF0537F1-30X CONNECTOR MAIN PWB FFC/FPC (1-30)
 F1601 NMFZ007-R20X-K FUSE 0.2A 50V
 F1602 NMFZ007-R50X-K FUSE 0.5A 50V
OT1 LY44587-001A SHEET(MDA) MECHA
OT2 LY30034-080A SPACER(A) IC1601
OT3 LY30034-036A SPACER(A) FOR IC1001
OT4 LY30034-037A SPACER(A) FOR IC2201
WR1 WJT0142-001B E-CARD WIRE MAIN PWB
 Symbol No. Part No. Part Name Description Local
PW1 YB10460A-01 FRONT BOARD ASSY
IC401 RPM7138-S IR DETECT UNIT IR
Q401 RPM-22PB PHOTO TRANSISTOR W/B
Q6501 DTC114EM-X DIGI TRANSISTOR
Q6502 EMT1-W PAIR TRANSISTOR
Q6503 EMT1-W PAIR TRANSISTOR
Q6504 2SA2029/QRS/-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
D401 SML-211UT-X LED TALLY
D6501 LWE67C/U2V45C/X LED WHITE
D6502 LWE67C/U2V45C/X LED WHITE
D6503 LWE67C/U2V45C/X LED WHITE
D6504 LWE67C/U2V45C/X LED WHITE
C401 NBXJ0JM-106X TA E CAPACITOR
C402 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
R401 NRSA6AJ-152W MG RESISTOR 1.5k Ω 1/16W J
R402 NRSA6AJ-470W MG RESISTOR 47 Ω 1/16W J
R6501 NRSA6AJ-561W MG RESISTOR 560 Ω 1/16W J
R6502 NRSA6AJ-121W MG RESISTOR 120 Ω 1/16W J
R6503 NRSA6AJ-120W MG RESISTOR 12 Ω 1/16W J
R6504 NRSA6AJ-120W MG RESISTOR 12 Ω 1/16W J
R6505 NRSA6AJ-120W MG RESISTOR 12 Ω 1/16W J
R6506 NRSA6AJ-120W MG RESISTOR 12 Ω 1/16W J
L401 NQR0265-001X FERRITE BEADS
BT401 QAB0040-001 LITHIUM BATTERY
CN401 QGF0532F2-12X CONNECTOR MAIN PWB FFC/FPC (1-12)
S401 NSW0122-001X DETECT SWITCH EJECT SW
OT1 LY30034-038A SPACER(A) BT401
OT2 LY30034-028A SPACER(A) Q401
OT3 LY30034-042A SPACER(A) FOR FFC
 Symbol No. Part No. Part Name Description Local
PW1 YB10461A-02 MONITOR BOARD ASSY
IC7601 CXA3657R IC SONY MT+VF
IC7602 MM1613BN-X IC 3.1V
IC7604 DN8797MS-X IC
Q7501 2SD1664/QR/-W TRANSISTOR
Q7502 2SD1664/QR/-W TRANSISTOR
Q7503 DTA144EE-X DIGI TRANSISTOR
Q7503 or RN2104-X DIGI TRANSISTOR
Q7503 or UN9113J-X DIGI TRANSISTOR
Q7504 2SC4617/QR/-X TRANSISTOR
Q7504 or 2SC4738/YG/-X TRANSISTOR
D7601 UDZS5.6B-X Z DIODE 1.5k
Ω 1/10W J
C7501 NCZ1016-150X C CAPACITOR 15pF 2kV J
C7502 NCZ1016-150X C CAPACITOR 15pF 2kV J
C7503 NFV41HJ-183X MPPS CAPACITOR 0.018uF 50V J
C7504 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7510 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C7602 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7603 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C7607 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C7608 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C7609 NBE21AM-335X TA E CAPACITOR 3.3uF 10V M
C7610 NCB31HK-682X C CAPACITOR 6800pF 50V K
C7611 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7612 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7613 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7614 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7615 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7616 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7617 NBE21AM-106X TA E CAPACITOR 10uF 10V M
C7618 NCB20JM-475X C CAPACITOR 4.7uF 6.3V M
C7619 NCB20JM-475X C CAPACITOR 4.7uF 6.3V M
C7620 NCB21CK-474X C CAPACITOR 0.47uF 16V K
C7621 NCB21CK-105X C CAPACITOR 1uF 16V K
C7622 NCB20JM-475X C CAPACITOR 4.7uF 6.3V M
C7623 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7624 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7625 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C7626 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7627 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local
MODEL MARK
A
B
C
D
GR-DX67EK
GR-DX77EK
GR-DX77ER
GR-DX77EX
MODEL MARK
E
F
G
H
GR-DX77EY
GR-DX77EZ
GR-DX78EX
GR-DX97EK
MODEL MARK
J
K
L
GR-DX97EX
GR-DX97EY
GR-DX97EZ
