3-18(No.YF034)
VF BOARD ASSEMBLY <06>
SD BOARD ASSEMBLY <07>
C7628 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7629 NCB21CK-105X C CAPACITOR 1uF 16V K
C7630 NCB21CK-105X C CAPACITOR 1uF 16V K
R7501 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7502 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7506 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R7507 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R7606 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7608 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7609 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7610 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7611 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7612 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7613 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7614 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R7615 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R7616 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R7618 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
L7501 NQL76EM-680X COIL 68uH M
L7502 NQL76EM-220X COIL 22uH M
L7601 NQL04DK-100X COIL 10uH K
L7602 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L7603 NQL38DK-101X P COIL 100uH K
L7604 NQL04DK-100X COIL 10uH K
T7501 NQS0060-001X SW TARNSF
CN7601 QGF0530F3-20W CONNECTOR
MAIN FFC/FPC (1-20)
CN7602 QGF0530F3-20W CONNECTOR
MAIN FFC/FPC (1-20)
CN7603 QGF0530F3-24W CONNECTOR
LCD FFC/FPC (1-24)
F7501 NMFZ007-R40X-K FUSE 0.4A 50V
OT1 LY44581-001A SHEET(CUSHION)
WR1 QAL0548-001 FPC
Symbol No.
Part No. Part Name Description Local
PW1 YB10462A VF BOARD ASSY
Q7001 2SC4617/QR/-X TRANSISTOR
Q7001 or 2SC4738/YG/-X TRANSISTOR
D7001 E1S35AW0C501-X LED
D7002 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J
C7003 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7004 NCB21CK-105X C CAPACITOR 1uF 16V K
R7001 NRVA63D-682X CMF RESISTOR 6.8k
Ω
1/16W D
R7002 NRVA63D-272X CMF RESISTOR 2.7k
Ω
1/16W D
R7003 NRVA63D-390X CMF RESISTOR 39
Ω
1/16W D
R7004 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R7005 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7006 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
CN7001 QGF0532F2-20X CONNECTOR
MAIN FFC/FPC (1-20)
CN7002 QGF0532F2-20X CONNECTOR
LCD FFC/FPC (1-20)
Symbol No.
Part No. Part Name Description Local
PW1 YB10463A-01 SD BOARD ASSY
D8501 EMZ6.8N-X Z DIODE
C8501 NBZ0015-106X TA E CAPACITOR 10uF 6.3V M
C8502 NCBA1AK-104W C CAPACITOR 0.1uF 10V K
R8501 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8502 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R8503 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8504 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8505 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8506 NRSA6AJ-103W MG RESISTOR 10k
Ω
1/16W J
R8507 NRSA6AJ-0R0W MG RESISTOR 0
Ω
1/16W J
L8501 NQR0006-001X FERRITE BEADS
CN701 QGF0532F2-12X CONNECTOR
MAIN PWB FFC/FPC (1-12)
CN702 NNZ0104-001X SD CARD CONNE SD CN
S701 NSW0099-001X SLIDE SWITCH DSC/VIDEO
OT1 LY30034-026B SPACER(A) SD CN
OT2 LY30034-068A SPACER(A) DSC/VIDEO
Symbol No.
Part No. Part Name Description Local
MODEL MARK
A
B
C
D
GR-DX67EK
GR-DX77EK
GR-DX77ER
GR-DX77EX
MODEL MARK
E
F
G
H
GR-DX77EY
GR-DX77EZ
GR-DX78EX
GR-DX97EK
MODEL MARK
J
K
L
GR-DX97EX
GR-DX97EY
GR-DX97EZ
