SPECIFICATIONS
General
Format : VHS PAL standard
Power source : DC 11 V (Using AC
Adapter)
DC 6 V (Using battery
pack)
Power consumption
Viewfinder on : 3.7 W (GR-FXM41 only)
3.5 W (GR-FX17 only)
LCD monitor on: 4.3 W (GR-FXM41 only)
Signal system : PAL-type
Video recording system
Luminance : FM recording
Colour : Converted sub-carrier
direct recording
Conforms to VHS standard
Cassette : cassette
Tape speed
SP : 23.39 mm/sec.
LP : 11.70 mm/sec.
Recording time (max.)
SP : 60 minutes
LP : 120 minutes
(with EC-60 cassette)
Operating
temperature : 0°C to 40°C
Operating humidity
: 35% to 80%
Storage temperature
: –20°C to 50°C
Weight : Approx. 768 g
(GR-FXM41 only)
Approx. 690 g
(GR-FX17 only)
Dimensions : 81 mm x 125 mm x 216 mm
(W x H x D) (GR-FXM41 only)
75 mm x 124 mm x 221 mm
(GR-FX17 only)
(with the LCD monitor*
closed and with the
viewfinder fully tilted
downward)
* GR-FXM41 only.
Pickup : 1/6" format CCD
Lens : F1.8, f = 2.2 mm to 55 mm,
25:1 power zoom lens with
auto iris and macro control
Filter diameter : ø 30.5mm (GR-FXM41 only)
ø 40.5mm (GR-FX17 only)
Viewfinder : Electronic viewfinder with
0.24" black/white LCD
White balance
adjustment : Auto/Manual adjustment
LCD monitor* : 2.50" diagonally measured,
LCD panel/TFT active matrix
system
Speaker* : Monaural
* GR-FXM41 only.
Connectors
Video : 1 V (p-p), 75 Ω unbalanced,
analogue output (via Video
output connector)
Audio : 300 mV (rms), 1 kΩ,
analogue output (via Audio
output connector)
Power requirement
:AC 110 V — 240 V~
50 Hz/60 Hz
Output : DC 11 V , 1 A
SPECIFICATIONS
Camcorder
AC Adapter
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications
subject to change without notice.
