EN53
Controls
1 Dioptre Adjustment Control ................. Z pg. 10
2 Lens Cover Open/Close Ring
[LENS COVER] .................................... Z pg. 12
3 Video Light Switch
[LIGHT OFF/AUTO/ON] ...................... Z pg. 19
4 Snapshot Button [SNAPSHOT] ............. Z pg. 20
5 •Power Zoom Lever [T/W] .................. Z pg. 16
•Speaker Volume Control [VOL.] ........ Z pg. 37
6 Picture Stabilizer Button
[P.STABILIZER] ..................................... Z pg. 18
7 Program AE Button [P.AE]..................... Z pg. 22
8 Fade/Wipe Button [EFFECT] ................. Z pg. 21
9 •Rewind Button [
2
, REW] ................ Z pg. 36
•Retake Rewind Button [RETAKE R]..... Z pg. 17
•Quick Review Button [ R] ............. Z pg. 17
0 •Fast-Forward Button [
3
, FF] ............ Z pg. 36
•Retake Forward Button [RETAKE F] .... Z pg. 17
! Stop Button [5 , STOP] ......................... Z pg. 36
@ Play/Pause Button
[
4
/6, PLAY/PAUSE]............................. Z pg. 36
# •Select Dial [+, –, PUSH] ................ Z pg. 7, 26
•Bright Dial [BRIGHT] ........................ Z pg. 15
$ MENU/DISPLAY Button ................. Z pg. 13, 26
% •Counter Reset/Memory Button
[COUNTER R/M] .............................. Z pg. 38
•Recording Mode Button [SP/LP] ........... Z pg. 8
^ EJECT Switch ......................................... Z pg. 9
& Recording Start/Stop Button.................. Z pg. 12
* Power Switch ................................ Z pg. 12, 36
( Battery Release Switch
[BATTERY RELEASE] .............................. Z pg. 4
) PUSH Button ......................................... Z pg. 9
Connectors
q DC IN Jack ............................................ Z pg. 5
The connectors w to r are located beneath the
cover.
w Video Output Connector ...................... Z pg. 40
e Audio Output Connector ..................... Z pg. 40
r J Terminal [JLIP (Joint Level Interface Protocol)
Connector]
• Connect the editing cable when performing
Random Assemble Editing (
Z pg. 44 - 47).
• It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
• JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
t Tally Lamp ........................................... Z pg. 12
y Power Lamp ........................................ Z pg. 12
Other Parts
u Battery Pack Mount ............................... Z pg. 4
i Viewfinder ........................................... Z pg. 10
o Grip Strap ............................................ Z pg. 10
p • Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor .................................. Z pg. 43
Q Video Light .......................................... Z pg. 19
W Microphone......................................... Z pg. 49
E Eyepiece
R Speaker ............................................... Z pg. 37
T LCD Monitor ....................................... Z pg. 15
Y Shoulder Strap Eyelets .......................... Z pg. 11
U Clock Battery Slot .................................. Z pg. 6
I Tripod Mounting Socket ....................... Z pg. 11
To Next Page
