GETTING STARTED
EN 11
GETTING STARTED
Controls
a Mode Switch [MODE] (墌 pg. 17)
b Light Button [LIGHT] (墌 pg. 31)
c Information Button [INFO/ ] (墌 pg. 38)
d Play/Pause Button [49] (墌 pg. 24, 29)
e Forward Search Button [ (
5
)] (墌 pg. 25)/
Right Button [ ]/Auto/Manual Mode Switch
[/] (墌 pg. 17)
f Forward Skip Button [ ] (墌 pg. 25)/Down
Button [ ]/Manual Set Button [ SET]
(墌 pg. 32)
g Reverse Search Button [ (
3
)] (墌 pg. 25)/
Left Button [ ]
h Menu Button [MENU] (墌 pg. 48)
i Delete Button [ ] (墌 pg. 39)
j Reverse Skip Button [ ] (墌 pg. 25)/Up
Button [ ]/Backlight Compensation Button
[] (墌 pg. 31)/Spot Exposure Control
Button (墌 pg. 31)
k Power Switch [OFF, , ] (墌 pg. 17)
l Lock Button (墌 pg. 17)
m LCD Lock Button
n Zoom Lever [T/W] (墌 pg. 23)
Speaker Volume Control (墌 pg. 24)
o Recording Start/Stop Button (墌 pg. 22, 28)
p Battery Release Button [BATT.] (墌 pg. 14)
Connectors
The connectors are located beneath the covers.
Q S-Video Output Connector [S] (墌 pg. 26)
R Audio/Video Output Connector [AV]
S USB (Universal Serial Bus) Connector (Refer
to the software installation and USB
connection guide.)
T DC Input Connector [DC] (墌 pg. 14)
Indicators
U Power/Charge Lamp [POWER/CHARGE]
(墌 pg. 14, 17)
V Access Lamp [ACCESS] (Lights up or blinks
when you access to any files. Do not turn off
the power or remove the battery pack/AC
adapter while accessing to files during
recording or playback.)
Other Parts
W Reset Hole [RESET] (墌 pg. 52)
X LCD Monitor
Y Speaker (墌 pg. 24)
a Battery Pack Mount (墌 pg. 14)
b Remote Sensor (墌 pg. 27)
Camera Sensor
c Lens
d LED Light (墌 pg. 31)
e Stereo Microphone
f Shoulder Strap Eyelet (墌 pg. 8)
g Grip Strap (墌 pg. 19)
h SD Card Cover (墌 pg. 20)
i Stud Hole (墌 pg. 19)
j Tripod Mounting Socket (墌 pg. 19)
